| Prod Model: |
DA SERIES |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
DIP Switch |
| Current: |
25mA |
| Voltage: |
24VDC |
| Material: |
Plastic |
| MOQ: |
29kgs/10kpcs |
| Size: |
52.5X29X48cm |
| Position: |
2, 3, 4, 5, 6, 7, 8, 9, 10, 12 |
| Fress Sample: |
Yes |
| OEM: |
Yes |
| Installation Form: |
Surface Mount |
| Structure: |
1-Point Contact |
| Package: |
DIP Plug Taping Package |
| Application: |
Security Products |
| Shape: |
Square |
| Shrapnel: |
Gold-Plated |
Product Description
SMD Terminal Right Angle DIP Switch With 2~12 Positions
--DIP switch is generally set address for a device generally this type of binary coded switches are now used it only two states, representing 0.1, its majority-digit 1-12, based on each of the state, form a binary number, the binary number is converted to decimal address code of the device.
Advantage
| NO.1 | Good quality! |
| NO.2 | 10 years manature! |
| NO.3 | Many types of circuit breaker switch we can supply |
| NO.4 | High quality, competitive price, great service! |
| NO.5 | The best indicator light at the best price! |
The Basic Technical Parameters
| Non-switghing Rating | 100MA 50VDC |
| Switching Rating | 25ma 24VDC |
| Contact Resistance | 50MΩ Max.at initial |
| Insulated Resistance | 100MΩ Min.at 500V DC |
| Dielectric Strength | 500V AC,1 Minute |
| Electrical Life | 2000 cycles |
| Operating Force | 400g~1000g |
| Stroke | 2mm |
| Material | PBT UL94V-0 |
| Terminal | Copper Alloy with gold plating |
Main Technical Parameters
| Experimental Current | Starting Condition | Experimental Time | Expect Result |
| 1In | Cold Start | 1h | Not Trip |
| 1.5In | Followed The Experiment | t<=1h | Trip |
| 2In | Cold Start | (t1)2s≤t≤60s(t2) | Trip |
| 6In | Cold Start | (t3)0.1s≤t≤2ss(t4) | Trip |
| 10In | Cold Start | (t5)0.02s≤t≤0.5s(t6) | Trip |
