Name: SMT LED PCB Stencils
Brand: all-electronics-online.com
SKU: 731643462
Availability: InStock
Rating: 4.5 (64 reviews)

Price:	US $ 1/Piece
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FD-010
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Complex
Flame Retardant Properties:	V0

Product Description

Basic Info

Model NO.: BIC-428-V4.28
Layers: Double-Layer
Certification: RoHS, ISO
Structure: Stencil Foils, Aluminum Framed
Foil Thickness.: 0.12mm, 0.15mm, 0.18mm, 0.2mm
Appearance: Engraving and Electro Polishing
Advantages2: B) Good Shape on The Window;
Fiducial Mark: Open for Fixed Position
Transport Package: Kk Carton (Hard Card)
Origin: China

Mode of Production: Laser Cut
Base Material: Stainless Steel Shim
Customized: Customized
Foil Thickness: 0.05mm, 0.06mm, 0.08mm, 0.1mm
Aperture Configured: Laser Cut
Advantages1: a) High Precision Dimension;
Advantages3: C) Hole Wall Is Smoother.
Specification: 520mm x 420mm

Specifications

Standard dimension:	370mm x 470mm, 420mm x 520mm, 550mm x 650mm
Structure	Stencil foils, Aluminum framed
Base material	Stainless steel shim
Foil Thickness(Optional)	0.05mm, 0.06mm, 0.08mm, 0.1mm, 0.12mm, 0.15mm, 0.18mm, 0.2mm
Aperture configured	Laser cut
Appearance	Engraving and electro polishing
Fiducial mark	Open for fixed position
Service area:	Worldwide
Quantity of open pads:
Advantages:	a) High precision dimension; b) Good shape on the window; c) Hole wall is smoother.
Application:	CSP, BGA, 0.5mm QFP etc. package

Frequently used Unit Conversion in PCB industry
1. Etched Method
Electrnics SMT Stencil for Printed Circuit Board Assembly

2. Laser Method
Electrnics SMT Stencil for Printed Circuit Board Assembly

1 inch= 25.4mm
1 inch= 1000mil
1 foot = 12 inch=0.3048 meter

1mm = 39.37mil
1mm = 1000µm
1µm = 39.37 micro inch

1oz = 35µm = 1.4mil = 305g/m²

1inch² = 0.0645dm² = 6.4516cm² = 645.16mm²
1ft² = 144 inch² = 0.09290304m² = 9.29dm²
1m² = 1549.9969 inch²
