Takfly Communications Co., Ltd. >> St Sm Simplex Customized Armored Fiber Optic Patch Cord

St Sm Simplex Customized Armored Fiber Optic Patch Cord

St Sm Simplex Customized Armored Fiber Optic Patch Cord
Price: US $ 3.5/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 10/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: TK-00112111
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Fiber Type: Single Mode
Cable Lenght: 10m,15m, or Upon Request
Lead Time: 2 to 3 Days
Free Sample: Available
Warranty: 1-3 Years
Sample: Available
Insertion Loss: Less Than 1dB
Return Loss: More Than 55dB
Color: Customized
MOQ: 1km
Application: Communication
Type: Single-mode Fiber
Connection Structure: ST
Certification: CE
Sheath Material: LSZH/PVC

Product Description

ST SM simplex customized armored fiber optic patch cord

Feature:
1. Conform to IEC,EIA-TIA, and Telecordia performance requirements
2. Together with custom connectors, the cable can be both water proof and gas proof and can withstand
   high temperatures.
3. Layouts can be wired much the same way as ordinary electric cable installations.
4. Anti rodent, save space, low cost construction
5. Improve stability & security
6. Easy installation, Maintenance
7. Available in different fiber types
8. Available in standard and custom lengths
9. RoHS, REACH & SvHC Compliant

Parameter:
ITEMSIMPLEXDUPLEXDESCRIPTION
Fiber count12
Tight Buffer                OD 0.6mm ± 0.05mm        OD 0.6mm ±0.05mm          Blue/Yellow
Kevlar 2 * 1110 dtex * 22 * 1110 dtex * 2Yellow
Outer JacketOD 3.0 +/- 0.2 mmOD 3.3 +/- 0.1 mmPVC, LSZH

ARMOURED FLEXIBLE TUBE:
Tube MaterialStainless
Inner Diameter1.5mm ± 0.2mm
Tensile Strength≤ 147N
Min. Bend Radius≥ 40 ± 5mm
Pressure Resistance≤ 2450/50mm



Thanks you for refer our products, should any question please feel free to contact me.
Takfly looking forward to hearing from you!!!
Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.

The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.

TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.

Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
