| Prod Model: |
LT10000HD |
| Model Number: |
Suntree |
| Output Voltage: |
360-440 |
| Types: |
DC/AC Inverters |
| Output: |
Triple, 3pH+N+PE |
| Input Voltage: |
1000V DC |
| Output Frequency: |
50/60Hz |
| Output Current: |
30A |
| Efficiency: |
98-99% |
| Operating Temperature Range: |
-25~60 |
| Short Circuit Production: |
Yes |
Product Description
LT 5000HD/LT 6000HD/LT 8000HD/LT 10000HD
Product installation example
1.Litto PV grid tied inverter is specially designed for outdoor installation, please install in the directions as shown in above diagrams.
2.Within 15 degrees vertical direction is recommended for the installaton.
3.Please install the inverter in the range of eyes can be check horizontally in order to check the working state and parameters of the LCD display and maintenance work.
4.Ensure the inverter is completely stable on the wall.
5.It is not recommended to install inverter under strong sunshine, in case of overheating reduce output power.
6.Environment temperature recommended of installation location is from -25 degrees to 60 degrees (-13 degrees to 140 degrees Fahrenheit).
7.Please ensure that the installation in a good ventilation environment, ventilation problems will affect the performance of the inverter internal electronic components and shorten the service life of the inverter.
1. How many years the quality guarantee of the on-grid solar inverter?
Normally 5 years quality guarantee, also can design 10 years quality guarantee if our customer require.
2. What type of the capacitor inside the inverter?
Film capacitor design.
3. How long does the service life for the on-grid solar inverter?
25 years of design service life.
4. Expect on-grid solar inverter, do you company also produce off-grid inverter?
Yes, we produce grid-connected solar inverter, off-grid inverter with batteries, and our engineers are endeavor to develop save energy inverter.
5. What's the after-sale service for your inverter?
We use WIFI, USB, GPRS, RS485 to monitor the working condition of the machine. Since every machine have a code, when something wrong with the machine, you just need to tell me your machine code, then we can monitor on internet and check out the real problems of the machine, then get back to you to solve it. No need to send it back to China.
