Suspension Type Composite Insulators

Name: Suspension Type Composite Insulators
Brand: all-electronics-online.com
SKU: 677710085
Availability: InStock
Rating: 4.5 (85 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CPT
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	15KV 70KN
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Polymeric Type:	Outdoor
Application:	Insulators
Material:	Composite Polymer
Structure:	Suspension Insulator
Type:	B Type Insulator

Product Description

Composite Pin Insulators are mainly used in high voltage overhead power transmission &distribution lines for insulation and mechanical connection.

Type	Rated voltage(kV)	Specified mechanical load(kN)	Section length(mm)	Min Arc distance(mm)	Leakage distance(mm)	Lightning impulse withstand BIL(kV)
FXBW4-12/70	12	70	350	180	400	95
FXBW4-24/70	24	70	550	370	850	185
FXBW4-24/100	24	100	570	370	850	185
FXBW4-35/70	35	70	650	450	1000	230
FXBW4-35/100	35	100	670	450	1000	230

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
