SVC Single-Phase High Accuracy Full Automatic AC Voltage Stabilizer
| Price: |
US $ 13.24-308.82/Piece |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
SVC |
| Display Screen: |
LCD/ LED/ Analog Meter |
| Certificate: |
Ce/ ISO9001 |
| Delivery: |
20days After Receiving Deposit |
| Input Voltage: |
160~250V |
| Outupt Voltage: |
220V+/- 3%, 110+/- 4% |
| Adjusting Time: |
< 1s (When Input Voltage Has a Change of 10%) |
| Protection Over Voltage: |
245+/- 5V |
| Delay: |
Short Delay 3~7 Sec Long Delay 3~7min |
| Ambient Temperature: |
-5~+40 Degree |
| Temperature Rise: |
< 60(Full Load) |
| Current Type: |
AC |
| Phase: |
Single Phase |
| Usage: |
SVC |
| Frequency Characteristics: |
Industrial Frequency |
| Frequency: |
50~60Hz |
| Brand: |
Honle |
Product Description
SVC Single Phase High Accuracy Full Automatic AC Voltage Regulator/Stabilizer
TECHNICAL INDEX
| Input Voltage | 280~450V |
| Frequency | 50~60HZ |
| Adjusting Time | < 1S(When input voltage has a change of 10%) |
| Rated Power | 6KVA 9KVA 15KVA 20KVA 30KVA 50KVA 60KVA 90KVA (optional) |
| Over Voltage Protection | 445±5V |
| Delay | Short Deley3-7sec long Delay 3-7min |
| Ambient Temperature | -5~+40 ºC |
| Waveform Distortion | No Waveform Distortion |
| Ralative Humidity | <90% |
| Insulation Resistance | ≥2MΩ |
| Efficiency | >95% |
| Temperature Rise | <60ºC(Full Load) |
APPLICATION
Conputers, test equipment, lighting systems, saftey alarm systems, X-ray systems, communication systems, medical equipment, stereo sound equipment, industrial automatic equipment, color film developing equipment, digital control machine tools, checkout equipment, TV sets, office appliances.
ADVANTAGES OF THE PRODUCT1) Novel design & Good quality
2) High voltage accuracy & High efficiency
3) Strong overload capacity & Fast response HOT SALES
FAQQ1:Would you accept to use our logo ?
A1: If you have good quantity,it's absolutely no problem to do OEM.
Q2: Can your product be customized?
A2: No problem. We have 5 senior engineers in our R&D Dept. and can design the product according to your special requirements.
Q3: How about the quality of your product?
A3: All the product have passed CE certification and ISO9001 quality management system certification. The professional technical ability, high quality components and strict testing procedure can ensure the quality of the product.
Honle Electric Co., Ltd is the manufacturer specialized in producing industrial electrical products. It has three factories, the first one produces power supply, the second one produce power transformer, the third one produces complete plants and equipment. As a member of China Power Supply Society, since its foundation, the company has been insisting on the theoretic guideline of "science &technology is the first productive force" and holding up brand strategy as the guide, relying on forward understanding about power supply technology, perfect craft and unwearied pursuing to quality, we can show top quality power supply products, and set up fine image in Chinese market and overseas market.
Up to now, Honle has the modern workshops and advanced production devices. Besides, the company always introduces technology positively, reforms craft continuously, devotes to researching and developing the voltage stabilizer, regulator and power supply, precise pureness power supply, providing, marketing for products. The company always do researching and developing the stabilized voltage power supply, precise pureness power supply, providing marketing for products. In addition, the company tries to find excellent administrators and technical talents. After just a few years of continuous efforts, Honle has been improved on the aspect of varieties, production scale, management mode. So products manufactured by Honle have reached advanced technical level, they are not only popular with a great many customers in China, but also in foreign countries.
The products of our company have been approved by Shanghai Quality Supervision & Inspection Institute, and insured by PICC company. Honle insists on the quality of survival, innovation and development all the time, and it has passed ISO9001 quality management system certification. Relying on rich economic strength, fine production engineering, innovating management mode, we can dare to meet kinds of challenges from China entering WTO. That is helpful for establishing reinforced foundation of international business.
