Switching Power Supply - CF04 Series

Name: Switching Power Supply - CF04 Series
Brand: all-electronics-online.com
SKU: 690347821
Availability: InStock
Rating: 4.7 (114 reviews)

Price:	US $ 175-190/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CF04
Warranty:	1 Year
Input Voltage:	220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Self-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CCC
Output Type:	Single or Dual
Output Power:	60 - 90W
Brand:	BOER

Product Description

Specification Summary
The CF04 Range with 200W output power, it has a wide range of output voltages to select from. Both single or dual outputs are available. The power supplies are protected from overload, short circuit and sparks. They are able to be used off-load without any charges in output voltage.

Input Specification

Input Voltage	110Vac or 220Vac
Input Current	Less than 400mA at 220Vac
Input Frequency	50Hz

Output Voltage Range

CF04 4/8kV	Collector / Ionizer	4kV/8kV
CF04 4.5/9kV	Collector / Ionizer	4.5kV/9kV
CF04 5/10kV	Collector / Ionizer	5kV/10kV
CF045.5/11kV	Collector / Ionizer	5.5kV/11kV
CF04 6/12kV	Collector / Ionizer	6kV/12kV

Output Specification

Load Regulation	Less than 0.1%
Line Regulation	Less than 0.1%
Temperature Drift	Less than 400ppm/ºC when operating<55ºC
Voltage Ripple	Less than 0.3%at full load

*for more information or specification, please dont hesitate to contact us

Suqian Boer High Voltage Power Supplies Co., Ltd, located in Suqian City, Jiangsu province, China, is a Hi-tech enterprise invested by Genvolt of UK. Our company dedicated to supply, design and manufacture of High Voltage Power Supplies.

We pride ourselves on quick decision making and fast design cycles. This equates to more cost-effective designs for special products and original equipment manufacture applications, simply because the time to get the end product to the customer is short. This is particulary true when we can use one of or many standard building blocks for power conversion and power supply control in the design.

Our engineers are highly experienced in the manufacture of a wide range of high voltage power supplies, high voltage equipment and high voltage components that conform to the ISO9001/2008 standard.

The Boer high voltage equipment portfolio varies greatly and includes high voltage power supply units, photomultipliers, large electron beam welding machines, capacitor charges, laboratory, analytical, military and X-ray equipment.

Whatever your high voltage requirement, Boer has the technical expertise and experience to meet your demanding application. For more information please dont hesitate contact our company.
