| Prod Model: |
Optical Fast Connector |
| Name: |
FC Fast Connector |
| Fiber Mode: |
Single Mode |
| Operation Time: |
About 60s(No Fiber Cut) |
| Insert Loss: |
≤ 0.3dB(1310nm-1625nm) |
| Return Loss: |
≥ -45dB |
| Fastening Strength Of Naked Fiber: |
>5 N |
| Fastening Strength Of Naked Fiber Holder: |
>10 N |
| Tensile Strength: |
>50 N |
| Using Temperature: |
-40~+75 |
| Warranty: |
3 Years |
| Transmission Medium: |
Single-Mode |
| Structure: |
SC |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
PC(',UPC) |
Product Description
Product Description
Promotion High Quality Adapter FC/UPC Fiber Optic Fast Connector
Specifications
1.Easy to assemble
2.Without further processing
3.Excellent stability
4.100% qualified
5.Applicable for 3.1 x 2.0mm drop cable or 3.0/2.0/0.9mm cable
Parameter
1.Optical fiber diameter: φ 125um (657A and 657B)
2.Tight buffer diameter: φ 250um
3.Fiber mode: Single mode
4.Operation time: About 10s (exclude fiber cut)
5.Insert loss: ≤ 0.3dB (1, 310 and 1, 550nm)
6.Return loss: ≤ -40dB
7.Fastening strength of naked fiber: >5N
8.Tight clamping force cladding: >8N
9.Tensile strength: >50N
10.Used temperature: -45° To +80° C
Features
1.Easy assembly, no need special assembling tool
2.Without further processing, such as polishing
3.Excellent stability with low insertion loss, 100% qualified
4.Can reduce the defect rate because of being able to reconnect
Specification:
| Series | FC Fast connector |
| Applicable Cable | P3 X 2 Rubber-insulated wire | Φ3.0 Fiber |
| Fiber Diameter | 125μm | 125μm |
| Coating Diameter | 250μm | 250μm |
| Fiber Mode | SM OR MM | SM OR MM |
| Installation Time | ≤40S | ≤40S |
| Construction Site Installation Rate | ≥99% | ≥99% |
| Insertion Loss | ≤0.5dB(typical value≤ 0.8dB)(1310nm or 1550nm) | ≤0.5dB(typical value≤ 0.8dB)(1310nm or 1550nm) |
| Return Loss | 45dB(average 50dB) | 45dB(average 50dB) |
| Tensile Strength | >30 | >20 |
| Working Temperature |
-40°C~+70 °C
| -40°C~+70 °C
|
Reusability
| ≥50 | ≥50 |
Normal Life
| 30 years | 30 years |
