Tension and Compression Load Cell (B323)

Name: Tension and Compression Load Cell (B323)
Brand: all-electronics-online.com
SKU: 831672945
Availability: InStock
Rating: 4.9 (22 reviews)

Price:	US $ 80-100/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B323
Size:	8060mm(HD)
Capacity:	5-5000kg
Accuracy:	0.03%
Load Direction:	Compression
Type:	Tension & Compression Load Cell
Pattern:	Tension and Compression
Out-Wire:	5 Wires
Feature:	High Accuracy
Production Process:	Stain Gauge

Product Description

1. Name: High accuracy tension Load Cells

2. Material and Capacity: 17-4PH S.S 5-5000kg

3. Details of Design (Design could be customized)

4. Datasheet

Specifications	Technique
Capacity	5,10,20,30,50,100,200,,250, 500,1000,2000,3000,5000kg
Rated output	2.0±2.5%mV/V
Zero balance	±2% F.S.
Non-linearity	0.03%F.S.
Hysteresis	0.03%F.S.
Repeatability	0.03%F.S.
Creep(30min)	0.03%F.S.
Temp.effect on output	0.05%F.S./10ºC
Temp.effect on zero	0.05%F.S./10ºC
Input impedance	385±50Ω
Output impedance	350±10Ω
Insulation	≥5000MΩ/100VDC
Recommended excitation	3-10V
Maximum excitation	15V
Compensated temp range	-10~60ºC
Operation temp range	-20~80ºC
Safe overload	150%F.S.
Ultimate overload	200%F.S.
Cable size	Φ5×3000mm
Weight approx.	0.1kg
Material	Stainless Steel
IP Class	IP66

5. Application details

Brans B323 Miniature Column Load Cell offers an impressive compact design for high capacity applications. With a diameter of 41mm, it is ideal for tight spaces. The B020 is offered in 17-4 PH stainless-steel in 5kg to 5000kg capacities with a raised surface radius to lower the possibility of off center loading.

6. Product Highlights:
High speed, low deflection
Minimal mounting clearance
Outer diameter 41mm, 25mm as height
17-4 PH stainless-steel construction
For use in both tension and compression
Utilizes metal foil strain gauge technology

Sub-Miniature Tension & Compression Load Cell (Miniature/Inline Threaded) could be made according to your own design.

www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
