Test Switch Type Terminal Blocks (SKJ-2.5SK / SKJ-4/2X2SK)

Name: Test Switch Type Terminal Blocks (SKJ-2.5SK / SKJ-4/2X2SK)
Brand: all-electronics-online.com
SKU: 636952485
Availability: InStock
Rating: 4.7 (123 reviews)

Price:	US $ 0.02-0.05/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SKJ 4/2X2SK, test switch terminal blocks
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Battery
Environmental Protection:	General
Connection Mode:	Push-Pull Connection
Shape:	Round
Contact Termination Form:	Screws Fixed

Product Description

Screw Clamp Terminal Blocks with Disconnect Functions
Knife disconnect terminal block with screw connection. The knife disconnect can now be opened thus inserting the test equipment in series in the current loop circuit. Closing the knife disconnect will re-establish the circuit so the test equipment can be removed. This procedure will prevent system down time, and miswiring as the wires do not have to be disconnected from the terminal blocks.

ITEM NO.	SKJ-2.5SK	SKJ-4/2X2SK
Order No.	01019	01095
Dimension
Width x Thickness x Height (mm)	52/6.2/46	64/6.2/46.4
Screw (mm)	M3	M3
Torque (Nm)	0.5-0.7	0.6-0.8
Stripping Length (mm)	8	8
Rated data
Voltage Rating (V)	400	690
Current Rating (A)	16	16
Wire section (mm² )	2.5	4
Wire Range
Rigid wire range(mm² )	0.2-4	0.2-6
Flexible wire rangemm² )	0.2-4	0.2-4
