Tgb1le-63 Electromagnetic Type RCCB
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
Tgb1le-63 |
| Model Number: |
Tgb1le-63 |
| Brand Name: |
Tengen |
| Poles: |
1p+N |
| Place Of Origin: |
Zhejiang, China (Mainl |
| Rated Working Current In (a): |
2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
| Rated Insulation Voltage Ui (V): |
500V |
| Rated Impulse Withstand Voltage Uimp (V): |
4000V |
| Rated Residual Action Current Ln (a): |
0.03A, 0.05A, 0.1A |
| Rated Residual No-Action Current Ln (a): |
0.015A, 0.025A, 0.05A |
| Rated Residual Current Max Breaking Time: |
0.15 |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Electric Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Insert |
| Poles Number: |
3 |
| Certification: |
CCC |
| Structure: |
RCCB |
Product Description
Specifications
1.High quality
2.Good service
3.Competitive price
4.CCC,IEC certification
5. High quality & 2 Years Warranty
Application
This series mini breaker is applied to protect the overload and short circuit of circuit in
the lighting and power distribution system of AC 50HZ or 60HZ, rates voltage 230V or
less for single-pole, 400V for the multi-pole, and rated current 63A or less. Under normal
condition, it may be also applied as the unfrequented make-break change-over in the circuit.
Main technical parameter
Pole |
1P+N/2P/3P/3P+N/4P |
Frequency (Hz) |
50Hz |
Rated working voltage Ue (VAC) |
1P+N/2P 230V 3P/3P+N/4P 400V |
Rated working current In (A) |
2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A |
2A, 4A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
Rated insulation voltage Ui (V) |
500V |
Rated impulse withstand voltage Uimp (V) |
4000V |
Rated breaking capacity lcn(A) |
C2-C63: 6000A D2-D63:4000A |
Transient tripper type |
C/D |
Rated Residual Action Current ln (A) |
0.03A, 0.05A, 0.1A |
Rated Residual No-Action Current ln (A) |
0.015A, 0.025A, 0.05A |
Rated Residual Current Max breaking time(s) |
0.15 |
Rated Residual Current on breaking capacity lm (A) |
2000A |
Using life |
Mechanical life |
4000times |
Electrical life |
2000times |
Grade of Protection |
IP20 |
Installation type |
DIN normal rail |
Installation class |
II, III class |
Ambient environment temperature |
-5°C~+40°C |
Altitude |
≤2000m |
Relative air humidity |
+40°C no more than 50%, +20°C no more 90% |
Installation environment |
If no impulse and vibration, the foreign field couldn't be the field 5 times.
|
