| Prod Model: |
M1-400 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Poles: |
3p 4p |
| Certificates: |
CE,CB,IEC,CCC |
| Pole: |
1p,2p,3p,4p |
| Rated Current: |
up to 3200A |
| Rated Voltage: |
AC 380V, up to DC1000V |
| Arcing Over Distance: |
0.0≤100 mm |
| Place Of Origin: |
Zhejiang, China (Mainl |
| Breaking Capacity: |
High Voltage Circuit Breakers |
| Operation: |
Electric Type |
| Speed: |
High-Speed Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCCB |
| Poles Number: |
3 |
| Certification: |
CE |
Product Description
Application
Molded Case Circuit Breakers TGM1 series (hereinafter called as TGM1 MCCB) is a newdesigned MCCB
Developed and manufactured adopting international advanced technology. TGM1 MCCB rated insulating
Voltage AC 800V is suitable for using in the circuit of AC 50Hz /60Hz, rated voltage up to 690V, rated
Working current up to 630A to distribute electric power and to protect the line and the equipment from being
Damaged due to overload, short current and under-voltage. It can also be used for infrequently switch and
Starting of motor and for motor overload, short circuit and under-voltage protections. TGM1 MCCB with the
Advantages of the small volume, high breaking capacity, short over-arcing (some of specification is zero
Arcing), strong anti-vibration and so on.
In accordance with the ultimate short circuit breaking capacity classified into three types:
Type L (standard), Type M (middle), Type H (high).
MCCB comply with the standards: IEC 60947-2 and GB/T 14048.2 Low voltage breakers
Classification according to rated current (A):
TGM1- 63: 10, 16, 20, 25, 32, 40, 50, 63A
TGM1- 100: 16, 20, 25, 32, 40, 50, 63, 80, 100A
TGM1-160: 100, 120, 140, 160A
TGM1-225: 100, 125, 140, 160, 180, 200, 225A
TGM1-400: 225, 250, 315, 350, 400A
TGM1-630: 400, 500, 630A
TGM1-800: 630, 700, 800A
TGM1-1250: 800, 1000, 1250A
Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.
From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:
1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.
2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.
3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.
4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on
5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on
Internationalization standard quality guarantee system:
The product quality of Tengen Group has been strictly controlled in each working procedure,
Many kinds of internationalization standard quality guaranteed system can be highly effective
Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently
Make sure of our product quality.
"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American
FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management
System authentication, CCC authentication, European Union CE safe Authentication, American UL
Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first
Side laboratory -- low voltage electric appliance test center which is the first connected with
International in China.
We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
