The Power Semiconductor Module (MTC 600A-800A)

Name: The Power Semiconductor Module (MTC 600A-800A)
Brand: all-electronics-online.com
SKU: 723857825
Availability: InStock
Rating: 4.4 (102 reviews)

Price:	US $ 82/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MTC 600A-800A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
It(AV):	200A, 250A, 300A, 400A, 500A, 800A
Vdrm/Vrrm:	400-2600V
Vtm/Itm:	1.9V/600A, 1.9V/750A, 1.9V/900A, 1.9V/1050A, 1.9V/
Idrm/Irrm:	30mA, 40mA.
Igt:	180mA, 200mA.
Ih:	100 Ma.

Product Description

The power semiconductor module (Mtc 600A-800A)

IT(AV): 200A, 250A, 300A, 400A, 500A, 800A.
VDRM/VRRM: 400-2600V
VTM/ITM: 1.9V/600A, 1.9V/750A, 1.9V/900A, 1.9V/1050A, 1.9V/1500A, 1.9V/2400A.
IDRM/IRRM: 30mA, 40mA.
IGT: 180mA, 200mA.
VGT: 2.5V, 3.0V.
IH: 100 mA.
Dv/dt: 800V/µ S
Di/dt: 100A/µ S,
Tjm: 125° C
Viso: 2500V(AC)

1. Festures:
Electrically-isolated chip and baseboard AC 2500V;
Sealing according to international standing;
Full crimping structure, sensitive to temperature and power cycle duty;
≤ 350A Air-cooling, ≥ 400A Air-cooling or water-cooling;
Easy installation and maintenance;
Welding technique under the protection of vacuum an hydrogen gas.
2. Typical applications:
UPS;
Light-dimmer;
Industrial heating controller;
Non=contact switch;
AC/DC motor controls;
Various rectifying power supplies;
Soft start;
Welder;
Converter;
Battery charge and discharge.

Type	IT(AV)	VDRM/ VRRM	/ VTM/ITM		IDRM/IRRM	IGT	VGT	IH	Tjm	Viso	Outline
Type	A	V	V	A	mA	mA	V	mA	degrees Celsius	V(AC)	Outline
MT 25A	25	400-2600	1.5	80	8	100	2.5	100	125	2500	MQ09
MT 55A	55	400-2600	1.5	80	8	100	2.5	100	125	2500	MQ09
MT 70A	70	400-2600	1.9	170	10	100	2.5	100	125	2500	MQ10
MT 90A	90	400-2600	1.9	270	15	100	2.5	100	125	2500	MQ10
MT 110A	110	400-2600	1.9	330	20	100	2.5	100	125	2500	MQ10
MT 130A	130	400-2600	1.9	410	25	150	2.5	100	125	2500	MQ11
MT 160A	160	400-2600	1.9	480	25	150	2.5	100	125	2500	MQ11
MT 200A	200	400-2600	1.9	600	30	180	2.5	100	125	2500	MQ12,13
MT 250A	250	400-2600	1.9	750	30	180	2.5	100	125	2500	MQ12,13
MT 300A	300	400-2600	1.9	900	40	180	2.5	100	125	2500	MQ12
MT 400A	400	400-2600	1.9	1050	40	200	3.0	100	125	2500	MQ14
MT 500A	500	400-2600	1.9	1500	40	200	3.0	100	125	2500	MQ14
MT 800A	800	400-2600	1.9	2400	40	200	3.0	100	125	2500	MQ15
MT 1000A	1000	400-2600	1.9	3000	40	200	3.0	100	125	2500	MQ15
MT 500*A	500	400-2600	1.9	1500	40	200	3.0	100	125	2500	MQ17
MT 800*A	800	400-2600	1.9	2400	40	200	3.0	100	125	2500	MQ18

NCR Industrial:

A) P. C. B Relays for household appliance industry

B) Latching Relays/Shunts/C. T. For Energy meter industry

C) Eletricity Measuring Meters

With professional manufacturing and reliable design concept, NCR is supplying superior Latching Relay, Shunt and Current Transformer to worldwide meter producers.

With decades of manufacturing experience, we are now enjoying a high reputation in the metering field worldwide. Our product range include Latching Relay and Shunt/Current Transformer used for 60-200A single & three phase energy meter. We have over 10000sqm production facilities, several automatic and semi-automatic production lines. With strong R&D capability, we are offering our clients one-step customized solutions and service.

Based on ISO9000 quality standard, we have set up strict IQC, IPQC and FQC system in our manufacturing, to ensure quality meeting IEC62055-31 standard and customer's requirements.

We'll always keep the spirit "offering the best products and outstanding service", to go along with all our clients together. By continuous steps, NCR is efforting to offer better products and more professional solutions to our users.

"Nice, Content, Reliable. It's NCR.
