Thermal bimetallic strip 5j20110(5j11)

Name: Thermal bimetallic strip 5j20110(5j11)
Brand: all-electronics-online.com
SKU: 710973742
Availability: InStock
Rating: 5 (65 reviews)

Price:	US $ 25-30kg
Min Order:	20kg
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	5j20110
Density:	7.7g/cm³
Use:	Circuit breaker, thermal protector
Linear Temperature Range:	-20~150
Allows The Use Of Temperature Range:	-70~200

Product Description

Thermal bimetallic strip 5j20110(5j11)

Main features: high heat sensitive properties and high resistivity, but lower elastic modulus and allowed stress, can increase the sensitivity of the instrument, smaller size and increase the reaction

shop sign		5j20110
With brand
Composite layer alloybrand	High expansion layer	Mn75Ni15Cu10(Mn72Ni10Cu18)
	middle layer	--------
	Low expansion layer	Ni36

Chemical composition

shop sign	Ni	Cr	Fe	Co	Cu	Zn	Mn	Si	C	S	P
shop sign	Ni	Cr	Fe	Co	Cu	Zn	Mn	Si	≤
Ni36	35.0~37.0	-	allowance	-	-	-	≤0.6	≤0.3	0.05	0.02	0.02
Mn72Ni10Cu18	8.0~11.0	-	≤0.8	-	17.0~19.0	-	allowance	≤0.5	0.05	0.03	0.02
Mn75Ni15Cu10	14.0~16.0	-	≤0.8	-	9.0~11.0	-	allowance	≤0.5	0.05	0.02	0.03

performance

Than bending K(20~135ºC)			Temperature curvature F/(greenhouse ~ 130 ºC)	resistivity		Linear temperature / ºC	Allows the use of temperature / ºC	Density (g/cm after)
Nominal value	Allowable deviation			Standard values	Allowable deviation
	Level 1	Level 2
20.8	±5%	±7%	39.0%±5%	1.13	±5%	-20~150	-70~200	7.7

Modulus of elasticity E/GPa	Hardness (HV)		Tensile strength MPa	Allow stress MPa
Modulus of elasticity E/GPa	High expansion layer	Low expansion layer	Tensile strength MPa	minimum	biggest
113~142	190~240	200~255	736~834	147	294

Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.

Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.

Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
