Three Phase 120W 380V Induction Motor

Name: Three Phase 120W 380V Induction Motor
Brand: all-electronics-online.com
SKU: 678527012
Availability: InStock
Rating: 5 (56 reviews)

Price:	US $ 57.8-90/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	6IK120
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Eastern Asia,Western Europe
Output Power:	120W
Insulation Class:	Class B
Using Teperature:	-10°- +40°
Using Humidity:	≤85%
Function:	Driving
Number Of Stator:	Single Phase or Three Phase

Product Description

Induction motor, AC Gear motor, Induction Gear motor

Specification:
1) Dimensions: 104X104mm
2) Power: 120W(6-140W For choose)
3) Voltage: 110V, 220V, 380
4) Speed: 1300, 1350, 2700, 2800rpm
5 Rated toque up to 39.2N. M
5) Reduction ratio: 3~ 200K & 250~ 2000K
6) Application: Medical appliance, packing mechanism, printing mechanism, cup making machine, textile machinery,

The datasheet and price range only typical data for reference, Gear motor's price are usually decide by Motor's reduction ratio and torque. Please fell free to contact with me if youwant this motor Specificaton or Drawing.

Model * Type		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN. m	Rated Torque mN. m	Rated Speed r/min	Capacitor μ F
Prnion Shaft	Round Shaft
61K120GU-AFJ (61K120A-AFJ)	61K120GU-AFTJ (61K120A-AFTJ)	120	1ph100	50	2.1	600	930	1250	30.0
				60	2.5		750	1550
61K120GU-EFJ (61K120A-EFJ)	61K120GU-EFTJ (61K120A-EFTJ)	120	1ph110	60	1.70	600	750	1550	20.0
			1ph120		1.80
61K120GU-CFE (61K120A-CFE)	61K120GU-CFTE (61K120A-CFTE)	120	1ph220	50	0.95	750	930	1250	8.0
			1ph230		0.95
61K120GU-HFE (61K120A-HFE)	61K120GU-HFTE (61K120A-HFTE)	120	1ph220	60	0.95	700	750	1550
			1ph230		1.0
61K120GU-SF (61K120A-SF)	61K120GU-SFT (61K120A-SFT)	120	3ph220	50	0.75	2200	890	1300	_

Ningbo Leison Motor Co. Ltd is a manufacturer and exporter of virious of motors,

Our Product range are:

DC Brush motor: 6-130mm diameter, 0.01-1500W output power.

DC Spur Gear Motor: 12-110mm diameter, 0.1-300W output power

DC Planeary Gear Motor: 10-82mm diameter, 0.1-1000W output power

Brushless DC Motor: 28-110mm, 5-1000W output power

Stepper Motor: NEMA 08 to NEMA 43, Can with gearox and lead screw

AC Gear Motor: 49 to 100mm diameter, 6-140 output power

Compare with other competitors, Our advantages are:

1) High Quality Guarantee: 10 years experiences in this field makes us have mature manufacturing process, Most of motors have CE, RoHS marks.

2) Competitive Price: We have a very high competitive ability of the list prices based on low cost labour force in China.

3) Good Service: LEISON MOTOR sales are professional and with good attitude, We will response with our customer within 24 hours(Holiday excepted), So you don' T need way about can' T not find the person when have agent things.

4) On Time Delivery: The delay delivery always are a headache problem for most of buyers, Our technical team and sales team make us can promise about 95% delivery on time.

5) Customized requirement: Beside normal products, We also design the motors according to customer requirement. Meanwhlile our MOQ is very low, (Even 1PC for some motors).

Still need more reasons? Now begin business with LEISON MOTOR, You will find we are a reliable and trustworthy in China.
