Three Phase Industrial UPS Power System with 10kVA to 120kVA

Prod Model:	CNI330
IP45 Degree:	Yes
Bypass Rated Frequency:	50Hz/60Hz
IP:	IP42
Current Harmonic Distortion:	<5%with Harmonic Filter
Rated Frequency:	50Hz/60Hz
Phase:	Three Phase
Type:	On-line
Protection:	Unbalanced Loads

Product Description

CNI330 Series Industrial Special Online UPS
10-200KVA (3Ph in/3Ph out)



High-reliability Industrial Grade Design:
The CNI330 system is composed of power special-purpose UPS, DBW regulator cabinet, PDU series feeder cabinet. CONSNANT Company apply herself to the development of China's electricity demands for power plants, substations, power distribution products are designed with online double conversion, zero conversion function. Main applications including electric power long distance, RTU, power carrier wave, power monitoring and so on. When the utility power is normal, single phase 220V(or three phase 380V.)  After isolation, rectification and filtering through the inverter to provide a stable power supply to the load; if the input AC power is abnormal or power failure, the backup power system by the DC screen provide power through non-return diode inverter. When the DC screen occurs voltage shortage or power break, the static switch transfer to bypass for power supply;  when the electricity is restored, the inverter automatically switches to utility power and provide power supply under inverter mode. If the inverter overload or fault and transfer power supply under bypass mode, also give a warning signal at the same time.

Application:
Petroleum, chemical industry, gas and power station and so on.


Key features:
Adopt full digital control technologyIntelligent detection and monitoring functionDigitally control the static switch with zero switchFull isolation between input and outputSuper low output zero earth voltageDC UPS isolated with utility power completelyCubical design with power standard (customization)Multifunctional protection for overvoltage, under voltage, over current, short circuit and over temperature and so on.Large-screen LCD monitor with Chinese and English operation interfaceUltralong 256 event record, user-friendly analysis and management to the situation of the power supply (touch screen optional)Static bypass has a strong anti-overload capability




Control system
It adopts microprocessor bus control technology, three core processor controlling rectification, inversion and parallel connection respectively, to ensure the real-time control of the rectifier, inverter and static switch and the coordination of every power part, characterized by increased control of aging, higher reliability, enhance of the efficiency of the whole UPS system and the output technical parameters are better than that of the device with same capacity.

Rectifier
6 pulse or 12 pulse fully controlled bridge (6  or 12 SCR) compose rectifier. Its function is to input AC 380V to DC220V or so by rectification. "slope" start (soft start) is the control feature, which means output voltage of the rectifier increase from 0V to 220V within 10 second and has no impact on the power grid.

Inverter
SPWM(sinusoidal pulse width modulation) , formed by 6 IBGT high power tubes, is composed of full-bridge-control. Its function is to transform DC voltage into sinusoidal AC voltage, boosting by the special (△/Y) zero phase shift zigzag type isolation transformer and become AC220V as load required. In addition, the transformer can eliminate like triple harmonics current that are reflected by non linear load from computer. Control features is the adoption of the "slow-down gate voltage" protection technology, greatly reducing disturbance of shutoff of the inverter (inverter and static switch shift mutually ), enhancing the overload capacity of the whole UPS system, which make the capability of anti-short circuit and anti overload of UPS far superior to the ordinary UPS, especially the anti shot circuit is unmatched by similar devices.


Large Capacity of Overload of the UPS Inverter
110% load --60'
125% load --10'
150% load --1'
200% single phase load --30"
Good Capacity of Resistance to Output Short Circuit Current Limiting and Period Load Impact

Advantages:
290% rated current -- 5": Even though a output short circuit or an overload occurs because of user's improper operation, the output current of UPS can still be limited to a controllable extent instead of exceedingly increasing, consequently laying a good foundation for a long-term and reliable operation of UPS.


Static switch
Not sync automatically switch:
When the bypass of the UPS lose sync with the inverter, system can automatically implement not sync switch, for example, when the utility power surge pulse width <5ms, the system can ensure no power cutoff.When the bypass exceed the limitation, UPS will detect the bypass every 20ms, when the phase angle difference of bypass and the inverter turn to normal range, not synchronized bypass shifting can be realized.


Optional bypass cabinet:
Isolating transformer and the bypass voltage regulation


Intelligent monitoring
Working status and data of UPS are transmitted to DCS system in real-time via RS232/RS485, passive contact and power transmitter, which finally realize Intelligent monitoring.

Unique option
SNMP cardDry contact cardSignal transmitterBypass isolation and voltage regulationIncrease feeder circuit (standard for 8 loops)12 pulse rectifierThe appearance of special models(standard dimension:800×600×2260mm)
Technical Specification:

Model Papacity(KVA)	10KVA	15KVA	20KVA	30KVA	40KVA	60KVA	80KVA		100KVA	120KVA
Capacity	8KW	12KW	16KW	24KW	32KW	48KW	64KW		80KW	96KW
lnput
Rated voltage	380/400 Vac three-phase
Voltage range	±20%
Frequency range	50/60HZ±5%
Power factor	≥0.8
Current harmonic distortion	<5%with harmonic filter
Soft Start	0-100% in10"
Bypass Input
Rated voltage	400Vac three-phase
Permitted voltage range	±15%(selectable from ±10% to ±25% from front panel)
Rated frequency	50/60Hz
Permitted frequency range	±2%(selectable from ±1% to ±5% from front panel)
Standard features	BackFeed portection; split bypass line
Batteries
Type	Maintenance-free lead-acid VRLA AGM / GEL;NICd
Maximum recharge current(A)	0.2 X C10
DC Voltage	384VDC							432VDC		480VDC
AC ripple voltage	<1%
Inverter output
Number of phases	3+N
Rated voltage(V)	400Vac
Regulation of the output voltage	348÷424Vac phase/neutral(from contril panel)
Crest factor(Ipeak/Irms)	3:1
Static stability	±1%
Dynamic stability	±5%
Frequency	50/60Hz configurable
Overload	110% 125% 150% of the rated current for 5h/10'/1'
Frequency stability	±0.05% on mains failure;±2%(selectable from ±1% to ±5%)with mains supply present
System
Remote signaling	Volt free contacts
Remote controls	EPO and Bypass
Communication	RS232 + romote contacts
Operation temperature	0ºC/ + 40ºC
Relative humidity	<95% non condensing
Colour	Light grey (RAL 7035)
Noise	54dBA at 1m				50-65dBA at 1m
Protection degree	IP42
Efficiency Smart Mode	up to 98%
Compliance	Safety:EN 62040-1-1(Directive 2006/95/EC); EMC:6200-2(Directive 2004/108/EC)
Weight(KG)N.W	200		220	230	290	340	440			520
Dimensions:(WxDxH)mm	600*800*1900									1200*800*1900
