| Prod Model: |
SLT86S01 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Step Angel Accuracy: |
+/-5% |
| Resistance Accuracy: |
+/-10% |
| Inductance Accuracy: |
+/-20% |
| Temperature Rise: |
80° C Max |
| Ambient Temperature: |
-10oc-+50oc |
| Insulation Resistance: |
100mmin.500 VDC; |
| Dielectric Strength: |
500V AC for One Minute |
| Shaft Radial Play: |
0.06max |
| Shaft Axial Play: |
0.08max |
| Insulation Cldss: |
Class B 130oc |
| Number Of Stator: |
Three-Phase |
| Excitation Mode: |
HB-Hybrid |
| Operate Mode: |
The Three Single Phase |
| Type: |
Magnetic-Electric |
| Brand: |
Slt |
Product Description
Character:
1,Voltage:4V-48V
2,Current:0.5A-10A
3,Resistor:0.2Ω-40Ω
4,Max brake torque:2-300 Oz-in
5, Step Angel Accuracy:+/-5%
6,Inductance Accuracy:+/-10%
7,Temperature Rise:+/-20%
Advantages
1,High torque
2,Low noise
3,Small size
4,Have the greatest torque motor stalling
5,Simple structure, easy to control cost
6,There are a wide speed range
Application:
1,Office equipment
2,Household appliances(Robots )
3,Financial instruments(ATM machine)
4,Industrial machinery(textile machine,carving machine;)
Technique parameter
| Technique parameter | Specifications |
| Step Angel Accuracy | +/-5% |
| Inductance Accuracy | +/-10% |
| Temperature Rise | +/-20% |
| Ambient Temperature | 80° C Max.(rated current, 2phase on) |
| Insulation Resistance | -10ºC-+50ºC |
| Dielectric Strength | 100MMin.500 VDC |
| Shaft Radial play | 500VAC for one minute |
| Shaft Axial play | 0.06Max. (450g-load) |
| Technique Specification | 0.08Max. (450g-load) |
Technique Specification
| Model | | 86H260-3004A | 86H260-4504A | 86H260-6004A | 86H280-3004A | 86H280-4504A | 86H280-6004A |
| voltage | V | 2.8 | 2.8 | 2.8 | 4.4 | 4.4 | 4.4 |
| current | A/phase | 3 | 4.5 | 6 | 3 | 4.5 | 6 |
| Phrase Resistance | /phase | 1.1 | 0.5 | 0.3 | 1.5 | 0.65 | 0.4 |
| Step angle | 1.8° | 1.8° | 1.8° | 1.8° | 1.8° | 1.8° | 1.8° |
| Rotor Inertia | gfcm² | 1000 | 1000 | 1000 | 1600 | 1600 | 1600 |
| Motor Weight | Kg | 1.7 | 1.7 | 1.7 | 2.4 | 2.4 | 2.4 |
| Motor Length | L(mm) | 60 | 60 | 60 | 80 | 80 | 80 |
Details structure
A, General precision of the stepper motor step Angle of 3-5%, and do not accumulate
B,Stepper motor torque vary with the increase of rotational speed will be reduced.
C, The step motor at low speed can operate properly, but above a certain speed won't be able to start, accompanied by squeaking noise
Packaging & Shipping
1,Inner packing(Waterproof plastic bag packing)+Outer packing(Carton packing)
2,Export wooden box packaging for products.
3,Other package as you required
