Three Phase10kVA~60kVA DC Voltage-Stabilizing Power Supply

Three Phase10kVA~60kVA DC Voltage-Stabilizing Power Supply
Price: US $ 3500-3900/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal,Money Gram
Prod Model: MZDC SERIES
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Current Type: DC
Phase: Three Phase
Usage: JIW
Frequency: High Frequency
Size: Small/Large
Application Range: Hotel/School/Oilfield/Railway
Brand: Meze

Product Description

Three Phase10kVA~60kVA DC Voltage-Stabilizing Power Supply

Model MZT301030153020303030403050306030803100312031403160320032503300
Nominal capacity10KVA15KVA20KVA30KVA40KVA50KVA60KVA80KVA100KVA120KVA140KVA160KVA200KVA250KVA300KVA
Working way and principleOn-line static bypass switch power supply,Double conversion technolog,The output power is completely isolated
Ac inputNumber of phasethree-phase+N+G
Voltage380V±20%
Frequency50ZH±15%
Single-phase maximum current(A)253340557186102133164195226257286366517
The power factor0.95
Soft start0-100% 5sec
Bypass the inputVoltage380v±15%
Frequency50HZ±5%
Conversion timenverter/The bypass(overload)Oms
Dc systemDc voltage384V(Battery 12 v32 section)384V/396V(Section 12 v32 / section 33)
Float charging voltage432V446V
As the voltage336V347V
The maximum discharge current(A)25425685113141169225282338400457571714857
Charging current10-25A
The acNumber of phasethree-phase+N+G
Voltage380±1%
Frequency50HZ±5%(mains)50HZ±0.05%(Battery power)
The load power factor0.8 Lag
Output waveformSine wave
Total harmonic distortionLinear load<3%  The nonlinear load<5%
Dynamic load voltage transients±5%(Change from 0-100% fall)
Transient recovery time<20ms ±5%
Unbalanced voltage±1%(Balance the load)
Overload capacity125%10min ,150%1min ,>150%220ms
System indicatorsThe work efficiency>91%,95% ECOEconomic model
Computer communication interfaceRS 232/RS422
Operating temperature0-40ºC
Relative humidity0~90% No condensation
Running high<1500,Each additional 100 meters, capacity by 1%, up to 4000 meters
Noise50db55db63db65db68db
StructureOverall dimensions(D*W*H)700*520*1100780*580*11901000*660*14601150*900*15001600*750*1600
 Weight (kg)1902303203654405206058501040111012501380150016002100
:


1. Welcome your enquiry
Contact me :leon liang

/Mob:+86 18824648626



Meze company was founded in 1999, so far, has developed into a comprehensive power supply enterprise, products include: UPS uninterruptible power supply, microcomputer non-contact electronic AC regulated power supply, EPS emergency power supply, etc. Main range: The financial, government, research institutes, transportation, aerospace, electronics, medical, services, etc. To meet the global electronic and communication industry for power equipment is increasingly vigorous market demand, Due to the need of development, shenzhen Meze power technology Co., Ltd was established in 2008 (Specialize in UPS power frequency, regulated power supply, and transformer) In the same year registered Meze electronics Co., Ltd. (Terminal blocks, all accessories of PCB), In 2011, registered shenzhen Meze mechanical and electrical Co., Ltd. ( SMT placement machine and accessories ).

Existing number of employees: 180-180 employees, Using area: 3000 square meters, Company has the high technology and rich experience, Products from well-known international brands of Europe, is committed to providing customers with the full range of high quality high performance high stable power supply protection. Using the international advanced intelligent digital UPS power supply technology, and the most advanced precision purification. Provide the most advanced, cutting-edge, the most reliable, the top power solutions.
