| Prod Model: |
ZN85S-40.5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
People |
| Rated Voltage: |
40.5kv |
| Rated Current: |
1250A,2000A, 2500A, 3150A |
| Customized Design: |
Yes |
| Rated Frequency: |
AC 50Hz |
| Breaking Capacity: |
High Voltage Circuit Breakers |
| Operation: |
Electric Type |
| Speed: |
High-Speed Circuit Breaker |
| Arc-extinguishing Medium: |
Vacuum |
| Installation: |
Fixed |
| Poles Number: |
3 |
| Certification: |
CCC |
| Structure: |
Vcb |
| Function: |
Overload, Shortcircuit Protection |
Product Description
IntroductionZW85-40.5 series AC high voltage vacuum circuit breaker can be used in the AC 50Hz, rated voltage 40.5kV three-phase electric net. Mainly are installed in the handcart type and fixed type switchgears.
For the protection & control of the electric equipments in mining ,iindustrial companies, power plants and substations.
Suitable for distribution systems and frequent operation places.
Surrounding1. Ambient temperature: -10ºC~+40ºC 2. Altitude below 1000m
3. Wind pressure ≤700Pa(Wind Speed is 34m/s)
4. Relative diary average temperature ≤95%, monthly average≤90%
5. Relative humidity diary average ≤ 2.2X10
-3MPa, monthly average ≤ 1.8X10
-3MPa
6. Shock degree ≤8 class.
Specification| Rated Voltage | 40.5KV |
| Rated short-circuit breaking current | 20KA, 25KA, 31.5KA, 40KA |
| Power frequency withstand voltage(1 min) | 95KV |
| Lightning impulse withstand voltage | 185KV |
| Rated short-time withstand current | 20, 25, 31.5KA |
| Rated peak withstand current | 50, 63, 80KA |
| Rated short-circuit duration | 4s |
| Rated short-circuit breaking current | 20KA, 25KA, 31.5KA |
| Rated short-circuit making current | 50KA, 63KA, 80KA |
| Breaking time | <80ms |
| single capacitor unit breaking current | 630A |
| back-to-back capacitor units breaking current | 400A |
| Rated short-circuit breaking current breaking times | 20 times |
| Rated operation voltage | AC/DC 110V, 220V |
| Mechanial life | 10000 times |
| Rated operating order | O-0.3s-CO-180s-CO(electric mechanism) |
Outline and mounting dimension
Packing and shipping-- Ordinary paper carton for products.
-- Shipping mark according to customer's request.
-- Bulk production will be deliveried by sea and air.

Our Service
-- We have our own factory, professional manufacturer
-- We can send you samples within two weeks.
-- We do OEM & ODM services .
-- We control quality strictly, quality problem: 100% compensation or change
Welcome to visit our factory. Welcome customer or your agent to inspect before order and before lading.
