Through Hole Package Type and Polypropylene Film Capacitor, 25UF/450VAC

Name: Through Hole Package Type and Polypropylene Film Capacitor, 25UF/450VAC
Brand: all-electronics-online.com
SKU: 780624655
Availability: InStock
Rating: 4.4 (133 reviews)

Price:	US $ 0.12/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	CBB60
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	UL ,Ce ,RoHS ,ISO9001 ,IEC60252
Life Time:	10000 Hours
Material:	Plastic Can or Al Can
Service:	OEM and ODM
Terminal:	Cable Wire Leading ,Tap
Type:	Polypropylene Capacitor
Application:	Fan
Package Type:	Surface Mount
Capacitance:	1-50uf

Product Description

1.Capacitor CBB60 Description:
1).Non induction winding structure of metallic polypropylene membrane.
2).Dry capacitor structure with no liquid materials, non-toxic, no leakage and environmentally friendly
3).Self-healing stability safety and high voltage withstand etc.
4).Low dissipation factor small inherent temperature rise
5).Small volume with light weight

2.CBB60 Capacitor Applications:
1).Single phase motors
2).Water pumps
3).Washing machines, cleaning machines
4).Domestic electric and health-machine
5).Fans
6).Lightings and lamps

Technical features:
1) Climate type: 40/70/21
2) Capacity volume variance: &Plusmn;5%, &Plusmn;10%
3) Testing voltage: between leading-out 1.75UR, 10S no breakdown
4) Between leading-out end and shell: 2,200V AC, 10S no breakdown
5) Insulation resistance: between leading-out ends: ≥3,000Mn.UF
6) Between leading-out end and shell: ≥1,000Mn
7) Loss tangent: ≤0.002 (50Hz)
8) Specifications: can be supplied according to customers' special needs

Capacitor Name	CBB60 Capacitor
Ralated Voltage	200-660VAC
Ralated Capacitance	1-150uF
Capacitance Tolerance	+/- 3% +/-5%
Dissipation factor(at 50Hz-Hz and 20°C)	≤0.002(100Hz,20°C
Life Expectancy	3000h(Class C) 10000H(Class B)
Frequency	50/60Hz
Reference Standard	EN 60252
