Tinned Copper Electrical Cable, PV Solar Cable DC1000/1800V 2.5mm2
| Price: |
US $ 0.21-0.25/Foot |
| Min Order: |
50000/Foot |
| Pay Type: |
L/C,T/T |
| Prod Model: |
Solar Cable,Photovoltaic Wire,Type PV Cables,PV1-F |
| Model No: |
PV1-F, Photovoltaic Wire, Type PV Cables |
| Test Voltage: |
6500V;50Hz |
| Ambient Temperature: |
-40 Centigrade up to 90 Centigrade |
| Smoke Emission: |
IEC 61034;En50268-2 |
| Fire-Resistance Performance: |
IEC 60332-1 |
| Approvals: |
TUV 2pfg 1169/0.8. 2007 PV1-F, UL 4703 Type PV Cables |
| Rated Voltage: |
600/1000 V AC/ 1000/1800V DC |
| Rated Voltage UL: |
600V, 1000V, 2000V |
| RoHS: |
Yes |
| Type: |
Insulated |
| Conductor Type: |
Stranded |
| Certification: |
RoHS |
| Brand: |
Rneda |
| Insulation Material: |
Polyolefin Copolymer Electron-Beam Cross-Linked |
| Conductor Material: |
Tinned Copper, Aluminum |
| Application: |
Photovoltaic Solar Station |
Product Description
Tinned Copper Electrical Cable,
PV Solar Cable DC1000/1800V 2.5MM2
APPLICATION PV Cable Pvf1-F 1169 PV solar cableConductor: Stranded bare copper or tinned CopperInsulation: ROHS thermosetting insulation material,prior color black or as customer's request.Sheath: LSZH&UV-resistant electron-beam cross-linked thermosetting Polyolefin copolymer ROHS material,prior color black or as customer's request
1.Nominal Voltage:U0/U=600/1000V AC, 1000/1800V DC ;2.Test Voltage:6500V,50Hz,5Min. 3.Temperature Rating:45oC upto+125oC, -40oF upto+257oF, Ambient temperature:25years(TUV) -40oC upto+90oC, -40oF upto+194oF, Max.Short circuit temperature:280oC, +536oF.5.Bending Radius:Fixed installation>4X Occasionally moved>5X| Construction | Conductor construction. | Conductor | Outer | Resistance Max. | Current Carring Capacity |
| nxmm2 | n/m | mm | mm | Ω/Km | A |
| 1X1.5 | 30/0.25 | 1.58 | 4.9 | 13.3 | 30 |
| 1x2.5 | 50/0.25 | 2.02 | 5.45 | 7.98 | 41 |
| 1x4 | 56/0.3 | 2.3 | 6.1 | 4.75 | 55 |
| 1x6 | 84/0.3 | 3.42 | 7.2 | 3.39 | 70 |
| 1x10.0 | 142/0.3 | 4.56 | 9 | 1.95 | 98 |
| 1x16.0 | 228/0.3 | 5.6 | 10.2 | 1.24 | 132 |
| 1x25.0 | 361/0.3 | 6.95 | 12 | 0.795 | 176 |
| 1x35.0 | 525/0.3 | 8.74 | 13.8 | 0.565 | 218 |
| 1x50.0 | 720/0.3 | 9.2 | 14.8 | 0.393 | 280 |
| 1x70.0 | 988/0.3 | 11 | 16.9 | 0.277 | 350 |
| 1x95.0 | 1349/0.3 | 12.5 | 18.7 | 0.21 | 410 |
| 1x120.0 | 1691/0.3 | 14.2 | 20.7 | 0.164 | 480 |
Applications Single conductor, sunlight-resistant, photovoltaic wire rated 90°C wet or 105°C dry 2000V for interconnection wiring of grounded and ungrounded photovoltaic power systems as described in Section 690.31(A) and other applicable parts of the National Electrical Code (NEC), NFPA 70ConstructionConductor: 8 AWG thru 1000 kcmil compact aluminum (8000 series)Insulation: Flame-retardant Cross-Linked Polyethylene (XLPE), black Options:Colored phase ID stripes available on requestMulti-plexing available on requestFeatures:Rated 90°C wet and dryDeformation-resistant at high temperaturesExcellent moisture resistance, exceeds UL 44Stable electrical properties over a broad temperature rangeExcellent resistance to crush and compression cutsResistant to most oils and chemicalsUV/sunlight-resistantMeets cold bend test at -40°CSpecificationsASTM B800 - 05(2011) Standard Specification for 8000 Series Aluminum Alloy Wire for Electrical Purposes - Annealed and Intermediate TempersASTM B801 - 07(2012) Standard Specification for Concentric-Lay-Stranded Conductors of 8000 Series Aluminum Alloy for Subsequent Covering or InsulationASTM B836 - 00(2011) Standard Specification for Compact Round Stranded Aluminum Conductors Using Single Input Wire ConstructionStandard
UL 4703 Type PVNational Electrical Code (NEC)ICEA S-95-658/NEMA WC70UL 44 Type RHH or RHW-2UL 854 Type USE-2c(UL) RWU90 1kVFor sizes less than 1/0: UL 1581 VW-1For sizes 1/0 and larger: IEEE 383, IEEE 1202/CSA FT4 | Size | Diameter of conductor | Min. Number of
Strands | Insulation
Thickness | Nominal O.D. | Net Weight | Maximum conductor resistance at temperature 20ºC |
| AWG or kcmil | mm | n | mm | mm | kg/km | Ω/km |
| 12 | 2.16 | 7 | 1.90 | 6.0 | 46 | 8.880 |
| 10 | 2.72 | 7 | 1.90 | 6.5 | 56 | 5.590 |
| 8 | 3.40 | 7 | 2.15 | 7.7 | 80 | 3.520 |
| 6 | 4.29 | 7 | 2.15 | 8.6 | 102 | 2.210 |
| 4 | 5.41 | 7 | 2.15 | 9.7 | 135 | 1.390 |
| 3 | 6.02 | 7 | 2.15 | 10.3 | 156 | 1.100 |
| 2 | 6.81 | 7 | 2.15 | 11.1 | 183 | 0.875 |
| 1 | 7.59 | 18 | 2.66 | 12.9 | 244 | 0.693 |
| 1/0 | 8.53 | 18 | 2.66 | 13.9 | 286 | 0.550 |
| 2/0 | 9.55 | 18 | 2.66 | 14.9 | 337 | 0.436 |
| 3/0 | 10.74 | 18 | 2.66 | 16.1 | 400 | 0.346 |
| 4/0 | 12.07 | 18 | 2.66 | 17.4 | 477 | 0.274 |
| 250 | 13.21 | 35 | 3.04 | 19.3 | 579 | 0.232 |
| 300 | 14.48 | 35 | 3.04 | 20.6 | 665 | 0.194 |
| 350 | 15.65 | 35 | 3.04 | 21.7 | 750 | 0.166 |
| 400 | 16.74 | 35 | 3.04 | 22.8 | 836 | 0.145 |
| 450 | 17.78 | 35 | 3.04 | 23.9 | 914 | 0.129 |
| 500 | 18.69 | 35 | 3.04 | 24.8 | 1028 | 0.116 |
| 550 | 19.69 | 58 | 3.43 | 26.6 | 1133 | 0.1060 |
| 600 | 20.65 | 58 | 3.43 | 27.5 | 1217 | 0.0967 |
| 650 | 21.46 | 58 | 3.43 | 28.3 | 1298 | 0.0893 |
| 700 | 22.28 | 58 | 3.43 | 29.1 | 1382 | 0.0829 |
| 750 | 23.06 | 58 | 3.43 | 29.9 | 1463 | 0.0774 |
| 800 | 23.83 | 58 | 3.43 | 30.7 | 1543 | 0.0725 |
| 900 | 25.37 | 58 | 3.43 | 32.2 | 1707 | 0.0645 |
| 1000 | 26.92 | 58 | 3.43 | 33.8 | 1871 | 0.0580 |
