TNC-Male-Twist-on-Connector

Name: TNC-Male-Twist-on-Connector
Brand: all-electronics-online.com
SKU: 799856045
Availability: InStock
Rating: 4.4 (110 reviews)

Price:	US $ 0.0001/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	T032
Item Name:	Twist RF Straight Crimp Connector 75ohm Rg59 RG6 F
Impedance:	75 Ohm
Withstanding Voltage:	500V RMS
Working Voltage:	170V Max
Frequency Range:	DC~1GHz
Vibration:	100m/S2 (10~500Hz)
Durability:	500 Times
Applicable Standard:	IEC 60169-24
Connector Type:	TV Antenna Connector

Product Description

TNC SPECIFICATIONS

Electrical
Impedance	50 Ohm nominal
Frequency Range	0-11 GHz
VSWR
M39012 Straight Connectors	1.3 max
M39012 Right Angle Connectors	1.35 max
Dielectric Withstanding Voltage	1500 VRMS
RF Leakage	-60dB min at 3 GHz
Insulation Resistance	5000 MΩ min
Contact Resistance
Center Contact	1.5 mΩ
Outer Contact	0.2 mΩ
Braid to Body	0.1 mΩ
Insertion Loss	0.18 dB at 9 GHz
Voltage Rating	500 volts peak

Environmental
Temperature Range	-65ºC to +165ºC
Clamp Gaskets	Clamps
Heat Shrink Tubing	Crimps
Hermetic Seals	Pass helium leak test of 2 x 10-8 cc/sec
Shock	Mil-STD-202, Method 202
Vibration	Mil-STD-202, Method 204 (test cond. D)
Moisture Resistance	MIL-STD-202, Method 106
Corrosion	Mil-STD-202, Method 101 ( test cond. B)
Temperature Cycling	Mil-STD-202, Method 102 (test cond. D)
Altitude	MIL-STD-202 Method 105 (test cond. C)

Mechanical
Mating	7/16 threaded coupling
Cable Affixment (Braid or Jacket)
All Crimps	Hex braid crimp
Clamps	Screw-thread nut and braid clamp
Cable Affixment (Center Conductor)
Crimps	Crimp or solder
All Others	Solder only
Captivated Contact
All Crimps	Yes
Others	Where specified
Cable Retention
Crimps	20-100 lbs
Clamps	20-50 lbs
