Top Quality Automatic Door Entrance Sensor with Ce Certificate

Name: Top Quality Automatic Door Entrance Sensor with Ce Certificate
Brand: all-electronics-online.com
SKU: 727137712
Availability: InStock
Rating: 4.4 (20 reviews)

Price:	US $ 40-50/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	PAD1003
Brand:	Bea
Frequency:	24.125GHz
Color:	Black
Size:	4.75in (W) X 3.15in (H) X 2.0in (D)
Detection Type:	Motion Detector

Product Description

Top quality automatic door open close sensor

Frequency:	24.125 GHz
Supply Voltage:	12 to 24 VAC: +/- 10%
	12 to 24 VDC: -10% / +30%
Mounting Height:	Normal: 7'; Maximum: 10'-0"
Tilt Angle:	0° to 90° Vertical
	-30° to +30° Lateral
Detection Area:
Wide	13ft (W) x 6.5ft (D)
Narrow	6.5ft (W) x 8.2ft (D) (supplied as optional)
Minimum Detection Speed:	2 in/sec (measured in axis)
Power Consumption:	<2W
Standard Output Relay:
Max Contact Voltage	60 VDC / 125 VAC
Max Contact Current	1 A (resistive)
Max Switching Power	30W (DC) / 60VA (AC)
Hold Time:	0.5 sec to 9 sec (adjustable)
Temperature Range:	-4°F to 131F °
Dimensions:	4.75in (W) x 3.15in (H) x 2.0in (D)
Weight:	0.5lbs
Material:	ABS
Housing Color:	Black. Can be painted with non-metallic paint.
Cable Length:	6ft

1. Shell 2. Light cross 3. Potentiometer to adjust sensitivity 4. Indicator light (LED)
5. Planar antenna 6. Cable connector
Technical data

Shanghai PAD Automatic Doors Technology Co., Ltd. is a company (manufacturer) established in 2003, located near the Hongqiao airport, Shanghai, China.
With CE and ISO9001: 2000 certificates, the company integrates Italian automatic technology and Chinese manufacturing advantages, which enables our products to have reliable quality and competitive prices.

Today PAD products are widely adopted in 89 countries or regions around the world, and more and more customers are joining us. For someof them we provide OEM service, and for some more we deliver the goods with PAD as our common brand.

Our main products include:
A. Automatic sliding door operator
B. Automatic revolving door systems.
C. Automatic roller motors.
D. Accesories for autoamtic door industry.

Our products are mainly used in restaurants, hotels, clubs, government buildings, offices, factories, shops, residential areas, military zones, etc.

As the society develops, our products are also progressing with the times. Sincerely hope we can provide our services for more cusotmers around the world.
Welcome you to have a visit to our factory!
