Top Quality Thermocouple Wire for Temperature Recorder

Name: Top Quality Thermocouple Wire for Temperature Recorder
Brand: all-electronics-online.com
SKU: 784346125
Availability: InStock
Rating: 4.3 (73 reviews)

Price:	US $ 0.65-0.7/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	K
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter:	0.2~1.5mm
Types:	K
Temperature Range:	-200~1200
Type:	Insulated
Conductor Type:	Solid
Application:	Underground
Conductor Material:	Chromel Alumel
Insulation Material:	PVC Singles

Product Description

Top Quality Thermocouple Wire for Temperature Recorder
The products is manufactured according to the standards of GB/T4989-1994 "Compensating Wire for
Thermocouples" and JB/T7495-1994 "Compensating Cable for Thermocouples".
This kind of products are mainly used as the connect wire in the automatic measure instruments in the
electronic power industry, chemical industry, petroleum industry, metallurgy industry and national
defense industry, etc.
More details about the product:

Types	K
Conductor Material	+Chromel , -Alumel
Insulation Material	Fused TFE Tape Duplex
Jacket	Fiberglass
Conductor diameter	0.2mm to 1.5mm
Temperature range	-200ºC-1200ºC
Standard	IEC584-2

Other sizes are available upon your request.

Type ,designation and kind of thermocouples

Type	Designation	Thermocouple	Thermocouple Grade ID
SC and RC	Copper-copper nickel 0.6 compensated compensating lead	Platonic-rhodium 10-platinum Thermocouple	S and R
SC and RC	Copper-copper nickel 0.6 compensated compensating lead	Platonic-rhodium 13-platinum thermocouple	S and R
KCA	Iron-copper nickel 22 Compensated Compensating Lead	Nickel-chromium nickel thermocouple	K
KCB	Iron-copper nickel 40 compensated compensating lead
KX	Nickel-chromium 10-nickel 3 prolonged compensating Lead / compensating cable
NC	Iron-copper nickel 18 compensated compensating lead	Nickel-chromium silicon-nickel thermocouple	N
NX	Nickel-chromium 14 silicon-nickel 4 prolonged compensating lead / compensating cable	Nickel-chromium silicon-nickel thermocouple	N
EX	Nickel-chromium 10-nickel 45 prolonged compensating lead / compensating cable	Nickel-chromium-cupronickel thermocouple	E
JX	Iron-copper nickel 45 prolonged compensating lead / compensating cable	Iron-constantan thermocouple	J
TX	Iron-nickel-chromium 45 prolonged compensating lead / compensating cable	Copper-constantan thermocouple	T
