Towel machine BLDC 24V electric motor with reduction gear

Prod Model:	DC Gear Motor with Encoders TRK-3530-1240
Product Name:	DC Gear Motor with Encoders TRK-3530-1240
Rated Voltage:	12V 24V
No-Load Speed:	5-950rpm
No-Load Current:	30-45mA
Rated Speed:	4-880rpm
Rated Torque:	0.2-10kg.cm
Rated Current:	180-250mA
Output Power:	1.4-3.1W
Stall Torque:	220-400g.cm
Stall Current:	1.0A 1.2A 1.3A
Application:	Power Tools
Operating Speed:	Low Speed
Structure And Working Principle:	Brushless
Excitation Mode:	Permanent Magnet
Casing Protection:	Drip-Proof
Type:	DC Gear Motor with Encoders
Certification:	RoHS CE
Brand:	TT Motor

Product Description

Towel machine bldc 24v electric motor with reduction gear

Main Features
1.OEM/ODM 37mm Eccentric out shaft gearbox plus 520 & 3530 & 3527 and TEC3650 &3640 brushless motor
2.Small size dc gear motor with low speed and big torque
3.37mm gear motor provide 1.0Nm torque and more reliable
4.Suitable to small diameter, low noise and big torque application
5.Dc Gear motors can match encoder,11ppr
6.Reduction ratio:6,10,19,30,44,56,90,131,169,270,506,810


Motor model no.	Rated voltage	No-load speed	No-load current	Rated speed	Rated torque	Rated current	Output power	Stall torque	Stall current
	VDC	r/min	mA	r/min	g.cm	mA	W	g.cm	A
TRK-3530-1240	12	4000	35	3300	40	180	1.4	220	1.0
TRK-3530-1250	12	5000	45	4200	40	250	1.8	250	1.2
TRK-3530-2460	24	6000	30	5300	50	180	3.1	400	1.3

Gear motor technical data  GM37-3530-1240-xxx

Reduction ratio	6	10	19	30	56	90	169	270	506	810
Length mm	19	19	21.5	21.5	24	24	26.5	26.5	29	29
No-load speed rpm	600	360	120	85	65	45	24	15	8	5
Rated speed rpm	550	330	110	85	65	45	24	15	6	4
Rated torque kg.cm	0.2	0.3	0.8	1.1	1.3	2.2	3.7	5.4	10	10
Max.momentary tolerance torque kg.cm	1.1	1.8	4.6	5.8	7.4	10	15	15	15	15

Gear motor technical data  GM37-3530-1250-xxx

Reduction ratio	6	10	19	30	56	90	169	270	506	810
Length mm	19	19	21.5	21.5	24	24	26.5	26.5	29	29
No-load speed rpm	800	490	165	110	88	55	30	18	10	6
Rated speed rpm	670	420	140	95	75	46	25	16	8	5
Rated torque kg.cm	0.2	0.3	0.8	1.1	1.3	2.2	3.7	5.4	10	10
Max.momentary tolerance torque kg.cm	1.1	1.8	4.6	5.8	7.4	10	15	15	15	15

Gear motor technical data  GM37-3530-2460-xxx

Reduction ratio	6	10	19	30	56	90	169	270	506	810
Length mm	19	19	21.5	21.5	24	24	26.5	26.5	29	29
No-load speed rpm	950	570	190	130	100	65	35	26.5	29	29
Rated speed rpm	880	530	175	120	95	59	35	22	10	7
Rated torque kg.cm	0.24	0.4	1.1	1.3	1.7	2.7	4.6	6.7	10	10
Max.momentary tolerance torque kg.cm	1.9	3.2	8.4	10.6	13.4	15	15	15	15	15

Product Application
Automatic door operators, automatic energy saving bath,electrical controlled valve,oxygen machine,optical equipment, Automat cordless power tool,lighting,etc.


Applications:
Business Machines:	ATM, Copiers and Scanners, Currency Handling, Point of Sale, Printers, Vending Machines.
Food and Beverage:	Beverage Dispensing, Hand Blenders, Blenders, Mixers, Coffee Machines, Food Processors, Juicers, Fryers, Ice Makers, Soy Bean Milk Makers.
Home Entertainment and Gaming:	Gaming Machines, Video Games, Optical Disk Drives, RC and Power Toys.
Home Technologies:	Home Ventilation, Air Purifiers and Dehumidifiers, Range Hoods, Washers and Dryers, Refrigerators, Dishwashers, Floor Care, Whirlpool and Spa, Showers, Smart Metering, Coffee Machines.
Lawn and Garden:	Lawn Mowers, Snow Blowers, Trimmers, Leaf Blowers.
Personal Care:	Hair Cutting, Hair Care, Massagers.
Power Tools:	Drills and Drivers, Sanders, Grinders, Polishers, Saws.
Camera and Optical:	Video, Cameras, Projectors.
