Triplex Overhead Aerial Bundled Aluminum Cables Urd Wire for AAC/ AAAC/ACSR Cable

Name: Triplex Overhead Aerial Bundled Aluminum Cables Urd Wire for AAC/ AAAC/ACSR Cable
Brand: all-electronics-online.com
SKU: 790373865
Availability: InStock
Rating: 4.6 (150 reviews)

Price:	US $ 1.66-8.88/Meter
Min Order:	2000/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	AAC/ AAAC/ACSR
Type:	Insulated
Conductor Type:	Stranded
Application:	Heating
Conductor Material:	Aluminum
Insulation Material:	XLPE
Certification:	CCC
Brand:	Jytop

Product Description

triplex overhead Aerial Bundled aluminum cables URD wire for AAC/ AAAC/ACSR cable

Construction of triplex cable
Concentric stranded or compressed 1350-H19 aluminum conductors, crosslinked polyethylene insulation. Insulated conductors surface printed, neutral triple yellow striped. Two phase and one neutral conductor twisted together(LH lay) or parallel if so specified. Black neutrals may be specified if desired.

Standards
ASTM B-230, B-231 and ICEA S-66-524 UL Standard 854 for Type USE Federal Specification JC-30B NEC

Specification :

Code Name	Phase Conductor			Neutral			Single Phase Conductor (in)	Outside Diameter (in)	Weight Per 1000ft (lbs)	Ampacity
Code Name	Size AWG	Strand	Insulation Thickness (mls)	Size AWG	Strand	Insulation thickness(mls)	Single Phase Conductor (in)	Outside Diameter (in)	Weight Per 1000ft (lbs)	Direct Burial	In Duct
Erksine	6	7/w	60	6	7/w	60	.299	.646	143	95	70
Vassar	4	7/w	60	4	7/w	60	.345	.754	203	125	90
Stephens	2	7/w	60	4	7/w	60	.403	.842	264	165	120
Ramapo	2	7/w	60	2	7/w	60	.403	.874	294	165	120
Brenau	1/0	19/w	80	2	7/w	60	.522	1.064	408	215	160
Bergen	1/0	19/w	80	1/0	19/w	80	.522	1.133	465	215	160
Converse	2/0	19/w	80	1	19/w	80	.566	1.174	502	245	180
Hunter	2/0	19/w	80	2/0	19/w	80	.566	1.228	560	245	180
Hollins	3/0	19/w	80	1/0	19/w	80	.616	1.276	606	280	205
Rockland	3/0	19/w	80	3/0	19/w	80	.616	1.336	678	280	205
Sweetbriar	4/0	19/w	80	2/0	19/w	80	.672	1.389	739	315	240
Monmouth	4/0	19/w	80	4/0	19/w	80	.672	1.457	828	315	240
Pratt	250	37/w	95	3/0	19/w	80	.748	1.538	893	345	265
Wesleyan	350	37/w	95	4/0	19/w	80	.851	1.736	1166	415	320
Holyoke	500	37/w	95	300	37/w	95	.979	2.008	1607	495	395
Rider	500	37/w	95	350	37/w	95	.979	2.035	1663	495	395
Fairfield	750	61/w	110	500	37/w	95	1.188	2.086	2304	615	525

Zhengzhou JINYUAN Wire and Cable Co., Ltd, as a professional cable manufacturer. We have get ISO9001 and CE certificates. Our Professional and complete cable solutions make JYTOP Cables become to the partner of choice for international companies around the world,

PRODUCTS & STANDARDS & International Market:

1). Bare Conductor:

All Aluminum Conductor (AAC),

All Aluminum Alloy Conductor (AAAC),

Aluminum Conductor Steel Reinforced (ACSR),

Aluminum Alloy Conductor Steel Reinforced (AACSR),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW),

Aluminum Conductor Aluminum Alloy Reinforced (ACAR),

Aluminum Conductor Steel Supported (ACSS),

Aluminum Conductor Aluminum Coated Steel Reinforced (ACSR/AW)

All Copper Conductors(ACC),

Aluminum Coated Steel Wire(ACS),

Copper Coated Steel Wire(CCS),

Copper Coated Aluminum(CCA),

Galvanized Steel Wire(GSW),

Enameled Wire - Enameled round Aluminum Wire & Enameled round copper Wire

2). Overhead Cable:

Aerial Bundled Cable (ABC).

XLPE Cable,

Flexible Cable,

Single Core Cable,

2 Core Cable,

3 Core Cable,

4 Core Cable.

3). Building wire and cable:

THHN /THWN Cable

TW/THW Cable

PVC Insulated Wire,

XLPE Insulated cable.

4. Power Cable:

Armored /Non-armored Power cable

AWA Cable

SWA Cable

Standards: IEC, ASTM, AS/NZ, SANS, BS, DIN, NF, JISC, etc.

We can meet customers' special requirements, and provided OEM service.

Mainly Oversea Marketing: Southeast Asia, The Middle East, Africa, South America, so on.

We will be recognized as a professional Manufacturer in cable industry, through continuous improvement of our product quality, after sales service. We can give you the reliable solution for cable wires.

Company website: www.jytopcable.com
