Tsk-S Limiting Switch

Name: Tsk-S Limiting Switch
Brand: all-electronics-online.com
SKU: 764661695
Availability: InStock
Rating: 5 (95 reviews)

Price:	US $ 3-4/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	TSK-S102
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	CE
Pressing Type:	Spring Roller
Protection:	Dust-Proof
Size:	Small-Sized
Environment:	﹤250℃
Breaking Capacity:	General Type
Breaking Form:	Single Type

Product Description

SPECIFICATION:
1. Contact: 1NO+1NC
2. Max Current: 10A
3. Max Voltage: 250VAC

FEATURES:
1. Metallic bottom shell.
2. Stainless steel roller, punch and spring.
3. Strong electric property 10A, 250V, for 500,000 times.

RATED NUMBER:

Model	BHL	5000	5030	5050	5100	5200	5300
Operating Force	OF(max)	750g	750g	750g	750g	900g	150g
Release Force	RF(min)	100g	100g	100g	200g	200g	30g
Pre-travel	PT(max)	20°	20°	20°	1.8mm	1.8mm	30mm
Tripping Position	TP(±10%)	22.5°	22.5°	22.5°	2.0mm	2.0mm	22.5°
Movement Differential	MD(max)	10°	10°	10°	1.2mm	1.2mm	14°
Over Travel	OT(min)	75°	75°	75°	4.0mm	4.0mm	20mm
Over Travel	TT(min)	95°	95°	95°	5.8mm	5.8mm	50mm

Why Us?

1. Clients' benefit first.

2. Experinced in the line for more than 21 years.

3. Reasonable price and good source of raw material.

4. A group of professional inspectors monitor quality.

5. TUV, SEMKO, CE, CB, ROHS Approval for products.

6. Unique design for packing.

7. Experienced salesmen offer one-to-one service.
