Twin Tube Carbon Infrared Lamp

Twin Tube Carbon Infrared Lamp
Price: US $ 10-20/Piece
Min Order: 5/Piece
Pay Type: T/T,Western Union
Prod Model: IRTC22-40-800/33×15G
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

To order you must inform us the following features:
- Diameter of the heating emitter
- Length of the heating emitter
- Wattage
- Voltage
- Connection
- Termination type how you want the heater to be connected with the electricity (screws, cable, cap etc. )
- Special Features (holes etc. )

It would be better for our understand If you could send us a drawing with all the characteristics noted.
 Marks
 And
Numbers
Infrared Heating Lamp  Quantity      Unit Price   Total
   Amount
Description of Commodity     PCS        Nanjing
DLIRTC22-40-800/33 × 15G
B-type Spiral carbon
Gold reflector
F4 ceramic cap
Voltage =220V
Power = 4000W
Total length =800mm
Heated length =700mm
Lead wire length =800mm
Cross section =33×15mm
Horizontal burning position
3EUR 76.45
DLIRTC38-60-1300/33 × 15G
B-type Spiral carbon
Gold reflector
F4 ceramic cap
Voltage =380V
Power = 6000W
Total length =1300mm
Heated length =1200mm
Lead wire length =800mm
Cross section =33×15mm
Horizontal burning position
3EUR 108.58
DLIRT22-40-800/33 × 15G
B-type Tungsten
Gold reflector
F4 ceramic cap
Voltage =220V
Power = 4000W
Total length =800mm
Heated length =700mm
Lead wire length =800mm
Cross section =33×15mm
Horizontal burning position
3EUR 80.33
DLIRT38-60-1300/33 × 15G
B-type Tungsten
Gold reflector
F4 ceramic cap
Voltage =380V
Power = 6000W
Total length =1300mm
Heated length =1200mm
Lead wire length =800mm
Cross section =33×15mm
Horizontal burning position
3EUR 115.23
Nanjing Dandy-Link Technology is a science & technology-oriented company that has been highly honored by the Government and Business Sector for our honest reputation for successive years. And we are invited in developing the newest GB/T 4654-2008 National Infrared Standards for non-metallic basic body infrared heater. The high-quality products and good services from Dandy-Link Technology have already built up its own brand reputation, it's also highly praised by many clients, and it's used to replace foreign brands. Our company's products have all passed the ISO9001 authentication, and are honored as "quality-credit guaranteed demonstration company" by the Light production quality guarantee centre for many years. Thereinto the infrared heating emitters were awarded as "reassurance brand" because they continuously passed the examines, and it was unfurled on the andand some other press.

Dandy-Link is a science & technology-oriented, quality-oriented, and service-oriented company, specialized in designing, manufacturing and developing the following products:

1. IR radiation heating emitters: High output IR radiation heating emitter (quartz heater), carbon fiber heater and IR radiation heating emitter with gold reflective coating.

2. Temperature and power controllers: Thyristor trigger(Thyristor zero crossing controller, Phase shift controller), Trigger module, Thyristor main circuit unit, Integrated Thyristor modular AC power controller and temperature control system.

3. IR radiation drying equipments: Infrared heating oven, Automotive paint baker and matched heating equipment sets.

We possess our own development group and core technology of said products. Therefore we have advantages over other similar products in advance and in quality. Our company's heating and temperature control products have a high technique jump-off point and a high quality/price rate, and considered more from the users' view, so that the reputation in the clients has risen quickly.

High quality Combined with our business concept of "Customer-centric", you will enjoy our suit and price-reasonable production, advanced and mature technology, comprehensive and consummate service. We believe that we can satisfy your company, and we hope we can have the opportunity to serve your company.

Any inquiry is appreciated.

Dandy-Link Technology_we can do better!

Anything need, please contact Anna: +86 18936279957.
