Type Mc-Copper Conductor-Aluminum Armor/Thhn/Thwn-2 Power Cable UL1569

Name: Type Mc-Copper Conductor-Aluminum Armor/Thhn/Thwn-2 Power Cable UL1569
Brand: all-electronics-online.com
SKU: 760158055
Availability: InStock
Rating: 4.9 (56 reviews)

Price:	Negotiable/Meter
Trade Terms:	FOB,CIF,EXW
Min Order:	1000/Meter
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	MC/AC/BX
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	600V
Conductor Insulation:	Thhn/Thwn or Xhhw-2
Insulated:	PVC
Sheathed:	Nylon
Armour:	Interlocked Alulmiumm Strip
Assembly Covering:	Polypropylene Tape
Grounding:	Insulated Green Grounding Conductor
Application:	Power Station
Voltage:	Low and Medium Voltage Cable
Current:	AC Cable
Insulation Material:	XLPE
Certification:	UL
Model:	Mc/AC/Bx Cable
Brand:	Rne Da

Product Description

Type MC-copper conductor-ALuminum Armor/thhn/thwn-2 power cable UL1569

MC Cable

Detailed products description:

1,UL standard:UL1569

2.MC cable(Metal clad)

3.specification:14awg-4/0awg

4.voltage rate:600v

Description of purpose:

MC cable is suitable for use as bellow:

1.Branch,feeder and service power distribution

2.Power,lighting,control and signal circuit.

3.Fished or embedded in plaster

MC cable, USA, UL & NEC standard, armored cable, metal clad cable, AC cable, BX cable, TECK cable, interlocked armored cable

Armor		Interlocked Aluminum Strip
Inner Conductor		Solid/ Stranded Copper
Conductor Insulation		THHN/ THWN OR XHHW-2
Assembly Covering		Polypropylene Tape
Temperature Rating		≤ 90 (dry); ≤ 75 (wet)
Grounding		Insulated Green Grounding Conductor
Voltage Rating		600V

References & Ratings
* UL 83, 1479, 1569, 1581
* NEC 230.43, 300.22(C), 392, 396, 330,
518, 520, 530, 645

Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220, 000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, large-scale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables. Submersible oil pump cables, . )and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa, Congo, Middle East and Southeast Asia countries and so on.

Products: Power Cable, Rubber Cable, UL standard building wire cable

Certificates:

Certificate of UL. CE, KEMA, TUV, Bureau Veritas, Lloyd, IEC, GL, SA, NK, KR and "National Industrial Production License", "Certificate of Recommended Enterprises and Products for National Grid", "Adopting International Standard Certificate", and "High-Tech Enterprise Certificate", "Certificate of High Quality Products", "Certificate of Scientific and Technological Achievements", "Qualified Supplier Certificate", "China Classification Society Certificate of Works Approval", "Det Norske Veritas Type Approval Certificate", "Railway Product Certificate", "Safety Certificate of Approval for Mining Products", "National Mandatory Product Certification", "Certificate for China Compulsary Products Certification" and "Practical New-Type Patent Certificate
