Zhejiang Wrlong High Temperature Wire & Cable Co., Ltd. >> UL 1901 Approval Awm FEP Insulation Stranded Wire

UL 1901 Approval Awm FEP Insulation Stranded Wire

UL 1901 Approval Awm FEP Insulation Stranded Wire
Price: US $ 0.06-0.7/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 10000/Meter
Pay Type: L/C,T/T
Prod Model: UL1901
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
UL Certificate: UL 1901
Temperature: 200 Centidegree
Voltage: 600V
Colour: Red, Blue, Green, Yellow, Brown, White
Feature: Chemical Resistance, Cut Resistance
Application Field: Household Appliance, Lighting
Type: Insulated
Conductor Type: Stranded
Application: Heating
Certification: RoHS
Conductor Material: Tinned Copper
Insulation Material: FEP Teflon
Range Of Application: Heat Resistance
Brand: Werle

Product Description

UL 1901 approval awm fep insulation stranded wire

Nominal Voltage: 600V

Temperature Range: -100 Degree~+200 Degree

O. D. Tolerance: ± 0.10mm

UL Approval

Testing Volta: 2500V

Conductor: Tinned Copper

Insulator: FEP TEFLON

Colours: Whit-bule-red-black-brown-yello-wgreen-transparent-yellow/green

They are the same with then inner fixed wires for Home Electric applinaces, Lighthing equipments, mechanical electrical machines
ConductorInsulatorElectrical CharacteristicPacking
AWGConductor
Construction
No./mm
Diameter
mm
Insulator
Thickness
mm
Over
Diamter
 mm
Realst.max
Cuc,c20oc ohm/km
Permissible
ampacity
20oc-AMP
mt/coils
301X0.250.250.200.65376.961.27610
281X0.310.310.250.81237.252.02610
267X0.150.460.331.12148.943.22610
19X0.100.500.331.16148.943.22610
247X0.200.610.331.2793.255.15610
19X0.120.600.331.2693.255.15610
227X0.250.760.331.4255.008.73610
19X0.150.760.331.4255.008.73610
207X0.310.950.331.6134.6013.87610
19X0.190.960.331.6234.6013.87610
187X0.391.190.331.8521.8022.02610
19X0.2351.180.331.8421.8022.02610
167X0.501.530.332.1913.7035.04305
19X0.301.510.332.1713.7035.04305
1419X0.371.860.382.568.6255.68305
1219X0.462.320.403.125.4388.40305
1037X0.433.020.504.023.41140.76305

ZHEJIANG WRLONG HIGH TEMPERATURE WIRE & CABLE Co., Ltd is a modernized enterprise which has specialized in high-temperature wire and cable for many years. It locates in the biggest production base of low-voltage appliance in China_YUEQING CITY, ZHEJIANG PROVINCE and it is next to OUJIANG rivers whose throughput is beyond thousands of ton every day as well. It is obvious that its transportation or traffic is very convenient and expeditious.

Our company owns the most advanced production equipment in China at present and we have imported the direct inverter microcomputer-controlled production line device from England. It has all sorts of detection device, abundant funds and trained professionally technicians as well.

Our leading products contain the teflon wire and cable which is used in Aerospace and Astronautics and high - temperature wire and cable which contains the fluoropolymers. Its types have AF46-200, AFK-250, AFPF-200, KFFR-250 and so on. Our company also produce high-temperature precise compensating conductor and its types are KX, KC, BC, SC, EX, IX, TX, NX, NC, EX and so on.

Our products have passed the certification of ISO9001-200, CCC, RoHS, UL and other test reports for the products from relevant organizations or institutions with the persistent efforts of all of the staff in WERLE and the products can find a ready market all over the world.

Our company sticks to regard the technology as guide, quality in pursuit of development as management ideas, quality create famous brands as tenet and thinks highly of quality management of the products in order to realize the integration of production, detection, selling and service and internationalization of the markets.

Society developping and make progresses gradually, WERLE strives with pressure, explore with urgence, struggle with blueprint and contend with smile for better future with the new and old clients together!
