UL 4703 Approved 12AWG PV Cable for Solar Power System

Prod Model:	PV
Products Name:	PV Cable
Standard:	UL 4703 Standard
Conductor:	Copper or Aluminum Alloy Conductor
Package:	Soft Package
Price:	Factory Price
Application:	Construction
Insulation Material:	XLPE
Certification:	UL
Voltage:	600 1000/2000V
Sheath Material:	None
Wire Core Material:	Copper ,Aluminum Alloy Conductor
Model:	PV
Brand:	Rneda

Product Description

 UL 4703 approved 12AWG  PV cable for solar power system

Standards:
Underwriters Laboratories Standards UL-4703, UL-854, UL-44
UL 1685-FT4/IEEE 1202 (70,000 Btu/hr) Flame Test (1/0 AWG and larger)
ICEA T-29-520 (210,000 Btu/hr) Flame Test
NEMA WC70/ICEA S-95-658
NFPA 70: National Electrical Code (NEC)

CONSTRUCTION:
Conductors:
Stranded conductors, uncoated copper per ASTM-B787 and ASTM-B8

Insulation:
Cross-linked polyethylene (XLPE) insulation per UL-854, UL-4703 and UL-44

Applications:
Type Photovoltaic copper conductors are suitable for outdoor rooftop applications without conduit and for use in conduits and raceways installed underground in conduit in wet locations, and where condensation and moisture accumulations within the conduit do not exceed 90ºC. Applications requiring direct burial is permitted for Type Photovoltaic per UL-854. Applications requiring type Photovoltaic conductor, temperatures shall not exceed 90ºC in wet or dry locations.

Features:
Available in 600V and 1000V/2000V. All cables comply with UL's VW-1 (Vertical Wire) Flame Test. Insulation compounds are rated for flame and sunlight-resistance in all sizes and colors. Photovoltaic conductors of 1/0 through 1000 KCMIL are rated for CT use. Sequential foot markings located every foot on master reels only for 1 AWG through 1000 KCMIL unless otherwise specified. RoHS compliant. Flexibility at Low Temperature Test. Carries -40 °C  rating.

		Insulation Thickness XLPE mm		Outside Diameter mm		Allowable Ampacity(Amps)		Approximate Net Weight(lbs/1000 ft)
Number of
Strands
SizeAWG	600V	1000V	600V	1000V	600V	1000V	600V	1000V	600V	1000V
		2000V		2000V		2000V		2000V		2000V
14	19	19	0.06	0.075	4.89	5.61	25	25	24	28
12	19	19	0.06	0.075	5.37	6.05	30	30	33	38
10	19	19	0.06	0.075	5.99	6.6	40	40	47	52
8	7*	7*	0.075	0.085	7.52	7.95	55	55	74	78
6	7*	7*	0.075	0.085	8.48	8.86	75	75	108	113
4	7*	7*	0.075	0.085	9.7	10.06	95	95	161	166
3	7*	7*	0.075	0.085	10.41	10.77	110	110	197	203
2	7*	7*	0.075	0.085	11.23	11.58	130	130	243	249
1	19	19	0.095	0.105	13.16	13.49	150	150	313	320
1/0	19	19	0.095	0.105	13.97	14.48	170	170	380	389
2/0	19	19	0.095	0.105	15.09	15.6	195	195	476	484
3/0	19	19	0.095	0.105	16.36	16.87	225	225	590	599
4/0	19	19	0.095	0.105	17.78	18.29	260	260	732	742
250	37	37	0.11	0.12	19.35	19.86	290	290	873	884
300	37	37	0.11	0.12	20.67	21.18	320	320	1035	1047
350	37	37	0.11	0.12	21.87	22.38	350	350	1198	1210
400	37	37	0.11	0.12	22.99	23.5	380	380	1358	1371
500	37	37	0.11	0.12	25.04	25.55	430	430	1680	1694
600	61	61	0.125	0.135	29.03	29.54	475	475	2057	2073
750	61	61	0.125	0.135	31.7	32.21	535	535	2508	2525
1000	61	61	0.125	0.135	35.61	36.12	615	615	3303	3322
