UPS Battery Deep Cycle Storage 12V 200ah Battery (QW-BV200A)

Name: UPS Battery Deep Cycle Storage 12V 200ah Battery (QW-BV200A)
Brand: all-electronics-online.com
SKU: 753327525
Availability: InStock
Rating: 4.8 (70 reviews)

Price:	US $ 165-225/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	QW-BV200A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	Lead-Acid Battery
Voltage:	12V
Nominal Capacity:	200A
Sealed Type:	Sealed
Terminal:	Cooper & Lead
Maintennance:	Free
Color:	Black
Size:	522240218mm
Weight:	54kg
OEM:	Accepted
Type:	Lead-Acid Batteries
Usage:	Boat
Nominal Voltage:	12V
Discharge Rate:	Low Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable

Product Description

UPS Battery Deep Cycle Storage 12V 200ah Battery (QW-BV200A)

QueensWing Battery:
Vrla battery: 12V 5A 7A 12A 17A 24A 38A 65A 100A 120A 150A 200A
Gel battery: 12V 5A 7A 12A 17A 24A 38A 65A 100A 120A 150A 200A

Main Characteristic:
1. Maintenance-Free Operation
Absorbent glass mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance. During the expected float service life of Prostar batteries, no need to check the specific gravity of the electrolyte or add water.

2. Good Discharging Ability
Tight assembly technology ensures an excellent high-rate discharge performance.

3. Long Service Life
A unique corrosion-resistant grid alloy ensures Prostar batteries have long service life.

4. Low Self Discharge
Using high purity raw materials ensures Prostar batteries have less self-discharge.

5. Environmental & Non-polluting
Gas Recombination technology ensures the battery high seal reacting rate, which can prevent the acid fog from separating out.

Applied Scope:
1)Communication Systems: Switch, Microwave Stations, Mobile Base Stations, Data Centers, Radio and Broadcasting Stations.
2)Motivity Field: Robots, Electric Toys, Electric Tools&Portable Vacuum Cleaners.
3)Solar&Wind Power Generation Systems
4)EPS&UPS Systems

Specifications:

Nominal Voltage			12V
Nominal Capacity (20 hour rate)			200Ah
Capacity 25 o C (77°F)		10 hour rate (11.0A)	190Ah
		5 hour rate (35.4A)	177Ah
		1 hour rate (132A)	132Ah
Internal Resistance		Full Charged Battery 25 o C	≤2.5mΩ
Capacity affected by Temperature (10 hour )		40 o C (104°F)	102%
		25 o C (77°F)	100%
		0 o C (32°F)	85%
		-15 o C (5°F)	65%
Self-Discharge 25 o C (77°F) Capacity		after 3 month storage	90%
		after 6 month storage	80%
		after 12 month storage	62%
Charge (Constant Voltage) 25 o C (77°F)	Float	Initial Charging Current Less than 40A Voltage 13.6-13.8V
Charge (Constant Voltage) 25 o C (77°F)	Cycle	Initial Charging Current Less than 40A Voltage 14.4-14.9V

Battery Dimensions	Length	522mm
	Width	240mm
	Height	219mm
	Total Height	224mm
Box Dimensions	Length	537mm
	Width	255mm
	Height	299mm
Quantity Per Box		1 PC per box
Net weight Per Cell		54.0 kg±500g
Net weight Per Box		54.0kg
Gross Weight		55.0kg
