| Prod Model: |
JYPU-600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Silvery White |
| Certificate: |
CE&RoHS |
| Output Type: |
Single |
| Warranty: |
18months |
| Output Connection: |
Crocodile Squeezer |
| Phase: |
Single Phase |
| Type: |
Line Interactive |
| Protection: |
Bat.Low Voltage Alarm&Shut Down,Overload,Over Temp |
| Brand: |
Jyins |
Product Description
JY — — Company code;
Δ — — P: Pure sine wave inverter M: Modified sine wave inverter
PU: Pure sine wave inverter with charger
MU: Modified sine wave inverter with charger
CH: Battery charger SC: Solar Controller;
SY: Movable solar power system;
Δ — — 75W, 100W, 150W, 200W, 300W, 500W, 600W, 800W,
1000W, 1200W, 1500W, 2000W, 2500W, 3000W, 4000W,
5000W, 6000W, 8000W, 10000W;
1210, 1215, 1220, 1230, 1250, 2410, 2415, 2420;
1205, 2405, 1210, 2410, 1215, 2415, 1220, 2420, 1230,
2430, 1250, 2450, 1260, 2460, 1280, 2480, 12100, 24100;
Δ — — Type: Type A, Type B, Type C, Type D, Type E, Type F, Type G;
Products Features:
· Input & output fully insolated
· High Surge: High surge current capability starts difficult loads such as TVs, camps, motors and other inductive loads,
· Grounding Protection: There is terminal in front panel, you can grouding the inverter.
· Soft start: Smooth start-up of the appliances.
· Pure sine wave output waveform: Clean power for sensitive loads.
· AC output identical to, and in some cases better than the power supplied by your utility
· Cooling fan in the inverter is thermally activated and comes on when the inverters becomes warm, and turns off automatically after the inverter has cooled.
· Low total harmonic distortion: Below 3%
· Two LED indicators on the front panel shows the working and failure state.
Protection Function:
· Low voltage alarm & Shutdown
· Over voltage protection
· Overload protection
· Over temperature protection
· Short circuit protection
· Reverse Polarity protection
· Soft start
· Auto. Reset after being in protected
· Grounding protection
| Model | CBPU600-121 | CBPU600-122 | CBPU600-241 | CBPU600-242 |
| Rated Power | 600W |
| Peak Power | 1200W |
| Output Waveform | Pure Sine Wave |
| Inverter | Input voltage | 12V | 24V |
| Output Voltage | 110V | 230V | 110V | 230V |
| Charger | Input voltage | AC 80-150V | AC 195-265V |
| Output Voltage | 12V | 24V |
| Max. Current | 10A | 5A |
| Transfer Time | less 15ms |
| USB Port | 5V, 500mA Optional |
| Protection Function | Bat. Low Voltage Alarm& Shut Down, Overload, Over Temperature, Overvoltage, ShortCircuit, Reverse Polarity, Overcharge etc. |
| Dimension | 248× 166× 128mm L× W× H |
| N. W. /unit | 2600g |
| QTY/Ctn | 6Pcs |
| Packing | Gift box |
| Meas. /Ctn | 58× 30× 45cm |
| Warranty | 18Months |
