USB Connector Panel Mount USB 3.0 Connector

Prod Model:	USB3.0 Pin SOCKET
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Connecting Mode:	Quickly Bayonet Connect
Protection Level:	IP65/IP67
Cable Specification:	0.15 mm2 ~ 0.2mm2 /26~24AWG
Diameter Range:	Od5.5mm ~7mm
Current Rating(a):	1.5A
Application:	Industrial
Grounding:	Standard Grounding
IP Rating:	IP65

Product Description

USB Connector Panel Mount USB 3.0 Connector

USB plugs and sockets are applicable to data transmission with quickly plug,fast transfer rate and strongly extensibility .With PBT shell performance stable, compression, anti-explosion and anti-deformation unique dock connecting to extend cable length and  Solid connections system can provide the solutions for data transmission in harsh environments, easy to install and operate.

They are widely used in computers,digital cameras,scanner and other transmission equipment.Varies types,can achieve male and female conversion docking,independent female,male with cable and so on.


 Data Sheet:

USB3.0 Female socket with pins
Specification
Connecting mode:	Quickly bayonet connect
Protection level:	IP67
Cable specification:	0.15 mm2 ~ 0.2mm2 /26~24AWG
Diameter range:	Φ5.5mm ~Φ7mm
Contact diameter×Qty:	9
Current rating(A):	1.5A
Withstand voltage(AC.V)1min:	1000V
Contact resistance:	<30mΩ
Insulation resistance:	>500MΩ
Durability:	≥500 mating&unmating cycles
Temperature rating:	-40°C~80°C
Method of connecting cable:	solder
Prevent the combustion level:	UL94-V0
Produce type:	Usb Panel Mount Connector
Material:
Shell&insulated parts:	High performance engineering plastics
Hardware metal:	Zinc alloy(pearl hard chromium)
Contact pin:	Copper alloy(gold-plated)
Spring:	Stainless steel
Sealing:	Silica gel
Main characteristics:
- Sealed against dust and fluid (IP65/IP68)
- Vibration resistance,impact resistance,stretching resistance
- With one hand, can quickly insert or pull out
Application industries:
- Stage equipment	- The smart grid
- Medical equipment	- Server
- Solar energy equipment	- Ship equipment
- Electric power equipment	- Vehicle equipment
- Communications equipment	- Heavy machinery


Packaging & Shipping

1. 5pcs to a box, 40 boxes to a carton,or use customized packing with MOQ1000 pcs/model boxes.
2. Lead time: 3-5 working days after received deposit for Usb Panel Mount Connector
3. DHL/UPS/Fedex/EMS/TNT(door to door) or use customer partner

Our Services

1. Supply OEM and ODM service for Usb Panel Mount Connector
2. With professional quality control system and R&D department
3. To make customized needs with national level laboratory
4.Free samples are available for Waterproof Usb Panel Mount Connector
5. supply the best service to you with the contact details below:
