UTP Cat. 6 Customer Branded Keystone Jack

Name: UTP Cat. 6 Customer Branded Keystone Jack
Brand: all-electronics-online.com
SKU: 764867755
Availability: InStock
Rating: 4.6 (74 reviews)

Price:	US $ 0.4-2/Piece
Trade Terms:	FOB
Min Order:	10000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	UTP Cat. 6
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current:	1.5AMP
Insulation Resistance:	More Than 1000 Megohm
Usage:	Workstation
Type:	Wired
Support Network:	Ethernet
Information Content:	Data
Certification:	ISO
Condition:	New

Product Description

UTP Cat.6 customer branded Keystone Jack

Description
UTP Cat.6 customer branded Keystone Jack meets international standardards TIA/ EIA568B and ISO/IEC 11801. It is a part of cat.6 link. Electrical performance meets the testing requirements of Cat.6 or Class E. It provides more than 250MHz bandwidth, processes redundancy performance margin, and it's suitable for transmission rate 2.4 Gbps high speed LAN.

Similar Products
UTP cat.5e keystone jack
FTP cat.5e keystone jack
UTP cat.6 keystone jack
FTP cat.6 keystone jack
UTP cat.3 keystone jack

Material
Shell: Polycarbonate, flame-retardant level meeting UL94V-0
IDC terminal: Phosphor-bronze 50μm overall gilding
Joint wire diameter: 22-24AWG

Application
10 BASE-T Ethernet
100 BASE-TX Fast Ethernet
1000 BASE-TX Gigabit Ethernet
155 Mbit ATM & 622 Mbit ATM
Other transmission rate 2.4Gbps LAN

Transmission Performance

Frequency (MHZ)	Insertion Loss dB(Max)	NEXT dB(Min)	FEXT dB(Min)	Return Loss dB(Min)
10	0.10	74.0	63.1	30.0
20	0.20	68.0	57.1	30.0
25	0.20	66.0	55.1	30.0
31.25	0.11	64.1	53.2	30.0
62.5	0.16	58.1	47.2	28.1
100	0.20	54.0	43.1	24.0
200	0.28	48.0	37.1	18.0
250	0.32	46.0	35.1	16.0

(All dates above are lab testing results, the actual testing results are not the same as these dates,
based on the actual testing results.)

Company profile
Cenyarak is a high-tech enterprise specialized in manufactureing computer network cables, connectors, fiber optic transmissions and other communication products. Cenyarak has a rich experience in providing services to top tier insistutions in the enterprise, health-care, education and carrier industries.
We have our own independent import and exports rights and we design and produce the products according to customer's requests. The prices of our products are evidently lower than the others which are the same grade on the condition of high quality.

Established in 2013, Jiangsu Cenyarak Electrical Co., Ltd is a manufacturer and trader specialized in research, development and production of all types of Fiber Optic Patch Cords and related products(). We are located in Jiangsu Nanjing, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets through the world.

Covering an area of 800 square meters, our company have own instrument processing center, manufacturing workshop, so that customized is available.

Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction. Besides, we have received _ISO90012008.

As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching North America, South East Asia, Europe, Africa ect.

Our company promises: High quality, reasonable prices, ample supply, timely delivery. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationship with new clients around the world in the near future.
