VDE Approved Electrical Cables H05VV-F 0.75mm*3c

Prod Model:	H05VV-F 0.75mm*3C
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	300/300V,300/500V,450/750V,600/1000V
Alternative Standard:	AS/NZS 5000,2:1999,Bs6004
Cores Number:	Multicore
Sectional Area:	up to 800mm2
Insulation Color:	Standard
Sheath Color:	Standard
Overview Type:	Round
Type:	Insulated
Certification:	VDE
Conductor Material:	Copper
Conductor Type:	Stranded
Insulation Material:	PVC
Application:	Domestic Use
Range Of Application:	Domestic and Industrial Wiring
Brand:	Yifang

Product Description

Specifications
electrical cable H05VV-F 0.75*3c
1.standard conductor VDE approved
2.standard power cable wire 2cores~4 cores
3.high quality
electrical cable H05VV-F 0.75*3c
VDE approved electrical cables H05VV-F 0.75mm*3C

Description of  electrical cable H05VV-F 0.75*3c :


H03VV, H05VV, H07VV cables

1. Rated temperature: 70°C

2. Rated voltage: 300V/300V, 300/500V, 450/750V

3. Core identification:

    2 cores: blue, brown;

    3 cores: green-yellow, blue, brown or black, blue, brown

    4 cores: green-yellow, black, blue, brown or black, blue, brown, black

4. Tinned or bare stranded copper conductor

5. Insulation: RoHs PVC

6. Jacket: Color coded PVC, RoHs PVC

7. European harmonized approved cables, VDE approved

8. Uniform insulation thickness to ensureeasy stripping and cutting

9. Resistant to acids, oil, alkali, moisture and fungus


Application of  electrical cable H05VV-F 0.75*3c:

?  Used for general purpose  internal wiring of electronic and electrical equipment, building wire for power,lighting and control wiring.

Packing of electrical electrical cable H05VV-F 0.75*3c:
50~100meters/roll, 1 roll/PE film, 2~4 rolls/carton boxes

Delivery time of electrical cable H05VV-F 0.75*3c:
20 days more or less after confirm t/t payment

Advantage of our factory:
1. More than 8years of producing many kinds of electric wires and cables
2. CCC/VDE/UL/Rohs certificates
3. Conductor can be used pure copper wrie or CCA cheap conductor.
4. Small MOQ 1000 meters, good service.
5. OEM are welcome. We can also produce standard or non-standard wires and cables.

More  electrical cable H05VV-F 0.75*3c can be produced as below per your request:



Style	Conductor		Insulation Thickness (mm)	Jacket Thickness (mm)	Overall Diameter (mm)	Voltage (V)
	Sectional Area(mm2)	No./mm
H03VVH2-F	0.5*2C	16/0.2	0.5	0.6	3.4*5.5±0.15	300
	0.75*2C	24/0.2			3.5*5.7±0.15
H03VV-F	0.5*2c	16/0.2	0.5	0.6	5.3±0.15	300
	0.75*2c	24/0.2			5.5±0.15
	0.5*3c	16/0.2			5.6±0.15
	0.75*3c	24/0.2			6.0±0.15
H05VVH2-F	0.75*2C	24/0.2	0.6	0.8	4.0*6.4	500
H05VV-F	0.75*2C	24/0.2	0.6	0.8	6.5±0.15	500
	0.75*3C				6.8±0.15
	1.0*2C	32/0.2			6.7±0.15
	1.0*3C				7±0.15
	1.5*2C	48/0.2	0.7	0.9	8±0.15
	1.5*3C				8.5±0.15
	2.5*2C	80/0.2	0.8	1.1	9.6±0.2
	2.5*3C				10±0.2


HO5VV-F electric flexible wire Description

 construction:
                     Conductor: stranded bare copper
                    Insulation: color coded PVC
                    Jacket: color coded PVC
                    Rated temperature:70ºC
                    Rated voltage: 300V/500V
                    Refer to standard VDE 0281 HD21,IEC227
Applications

For use in tool and appliance applications. Rated for continuous use from -40°C up to 70°C.

Available Certifications

    CE: 73/23/EEC, 93/68/EEC
    IEC: 60227-5, 60332.1
    VDE: 0281 Part-5
