VDE Standard N2xry Na2xry Power Cable

Name: VDE Standard N2xry Na2xry Power Cable
Brand: all-electronics-online.com
SKU: 711150762
Availability: InStock
Rating: 4.4 (35 reviews)

Price:	US $ 1-50/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	N2xry Na2xry Cable
Application:	Power Station
Current:	AC Cable
Insulation Material:	PVC
Certification:	RoHS
Voltage:	0.6/1kv
Wire Core Material:	Copper
Brand:	Yifang

Product Description

VDE Standard N2XRY NA2XRY Power Cable

This cable belongs to the low voltage cables voltage up to 0.6/1KV. They are used for power stations, industry and distribution boards and in subscriber networks.

Detailed cable structure as following:

N2XY Cable
Reference standard: VDE-0276 , IEC 60502
Conductor: Solid or stranded, plain copper conductor
Insulation : XLPE
Outer sheath: PVC

NA2XY Cable
NA2XY Cable is the same as N2XY Cable , but the conductor material is alumium

N2XCY Cable
Reference standard: VDE-0276 , IEC 60502
Conductor: Solid or stranded, plain copper conductor
Insulation : XLPE
Filler(if any): PP rope
Inner sheath: PVC
Concentric conductor: Helical copper wires with copper tape
Outer sheath: PVC

NA2XCY Cable
NA2XCY Cable is as the same as N2XCY Cable , but the conductor material is aluminium

N2XH/ N2XCH Cable
Reference standard: VDE-0276 , IEC 60502
Conductor: Solid or stranded, plain copper conductor
Insulation : XLPE
Filler(if any): LSOH filler
Concentric conductor for N2XCH: Helical copper wires with copper tape
Outer sheath: Thermoplastic polyolefin compound

N2XRY NA2XRY
Reference standard: VDE-0276 , IEC 60502
Conductor: Solid or stranded, plain copper conductor
Insulation : XLPE
Filler(if any): PP rope
Inner sheath: PVC
Armour layer: Steel wire armour
Outer sheath: PVC

NHXMH/(N)HXMH(St)
Reference standard: VDE-0276 , IEC 60502
Conductor: Solid or stranded, plain copper conductor
Insulation : Halogen free
Filler(if any): Halogen free filling compound
Outer sheath: Flame-retardant, halogen free

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
