Techcrepower Technologies Limited >> Wall Electrical Push Button Switch

Wall Electrical Push Button Switch

Wall Electrical Push Button Switch
Price: Negotiable/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Prod Model: AB-800A
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimensions: 86lx50wx20h(mm)
Standard Structure: Aluminum Panel, Steel Button
Contact Rating: 12-28V,3A
Output Contact: No/Nc/COM
Mechanical Life: 500, 000 Tests
Usage: Control Button

Product Description

wall electrical push button switch


Specifications:

Dimensions86Lx50Wx20H(mm)
Standard StructureAluminum Panel, Steel Button
Current Rating12-28V,3A
Output ContactNO\NC\COM
Mechanical Life500000 tests
Optional AccessoriesAB-800A-M
Suitable for DoorHollow Door
Operating temp-20~+55°C(14-131F)
Operating Humidity0-95% (relative humidity)
Panel MaterialAluminum panel, Sandblast Finished
Weight0.2kg
Standard Packing70pcs


Features:

Aluminum Panel with Elegant Style. tests.
Three Contact Output, Suitable for all kinds of Locks.
The Best Choice for Access Control.


Established in 2003, Shenzhen Techcrepower Technologies Limited (Subsidiary of Shenzhen Huake Tech. ) is specialized in R&D and production of access control Products, including RS485 and TCP/IP based control panel, IE web based Control panel, RFID network and single door offline access controller, wiegand reader and other peripheral access control products. As a manufacturer with strong developing team and production capacity, we always look at the forefront of the world advanced technologies, dedicated to developing the clients' most requested products, we always improving and improving!

We strictly control the quality and regard it as our base for existence! Our products are chosen high quality materials and ensure the prophase stability. Our 5 assembly line workers are well trained and can provide very professional work. All our products will be conducted aging test for 72 hours. QC staffs make piece-by-piece checks for all products. The RFID Reader monthly Production Capacity is 15000PCS in our ISO 9001: 2000-certified factory. With multi-kind of test equipments, our quality can be ensured to meet international Standards.

We are proud of our advanced technologies, top quality products, as well as fast services! At present, we are an affordable hardware provider, supply strong support for distributors, resellers and integrators. In future, we aim to become an excellent solution provider for SME (small & medium enterprise) in security sector!

Our Target: Provide cost-effective products and timely services with the concept of "one store purchasing", realize win-to-win cooperation!
