Wall-Mounted Humidity and Temperature Transducer for HVAC Applications

Name: Wall-Mounted Humidity and Temperature Transducer for HVAC Applications
Brand: all-electronics-online.com
SKU: 765960205
Availability: InStock
Rating: 4.4 (91 reviews)

Price:	US $ 28-40/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FHT20 Series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Display Type:	Digital

Product Description

Specially designed for HVAC, the FHT20 series by Focusens is a cost effective, highly accurate and reliable solution for measuring relative air humidity and temperature.

The enclosure minimizes installation costs and provides outstanding protection against contamination and condensation, thus ensuring flawless operation.

The FHT20 employs the new humidity / temperature Sensirion sensor element SHT21 with excellent long term stability and resistance against pollutants. In combination with a long calibration experience, the FHT20 provides a measurement accuracy of ±3%RH and is available for wall-mounted with current, voltage output.

Technical Data:

Parameter	Temperature	Relative Humidity
Measurement Range	0...+50°C -40...+60°C -20...+80°C	0...100% RH
Accuracy at 25°C	±0.3°C	±3% RH (20...80% RH)
Stability	<0.1°C / year	<0.5%RH / year
Response	<15s	<12s(63%)
power supply	2-wire: 12...24V 3-wire: 15...24V
Output	2-wire: 4...20mA 3-wire: 4...20mA / 0...1/5/10V
Load	2-wire: (VDD - 7V) / 0.02A 3-wire: Current mode less than 500Ω, Voltage mode greater than 10kΩ
Sensor protection	membrane filter
Housing material	Polycarbonate
Protection grade	IP65

Ordering Guide:

SERIES	OUTPUT	T-SCALING	DISPLAY
FHT20	(A) 2-wire current mode 4...20mA (B) 3-wire current mode 4...20mA (D) 3-wire voltage mode 0...10V (E) 3-wire voltage mode 0...5V (F) 3-wire voltage mode 0...1V	(T1) 0...+50°C (T2) -40...+60°C (T3) -20...+80°C	(D) LCD
