| Prod Model: |
GPS108 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dim: |
106mm X 63mm X 37.5mm |
| Main Feature: |
Large Battery Long Standby Time |
| Network: |
2g GSM/GPRS |
| Band: |
850/900/1800/1900MHz |
| Tracking By: |
SMS, Android APP, Web Server, Software |
| Battery: |
Chargeable 3.7V 10000mAh Li-ion Battery |
| Tracking Map: |
Real-Time Google Maps |
| Schedule Mode: |
10000*0.85 (Battery Self-Lost) /0.14mA/24h/365D=6. |
| Carrier Frequency: |
Dual-Frequency |
| Model: |
GPS108 Vehicletracker |
Product Description
Waterproof Large Battery gps tracking device car GPS108 With 6.9 Years Standby in Deep Sleep Mode
GPS Vehicle Tracker GPS108 is a Coban new product just launched in 2018, This tracker is based on the GSM / GPRS network and GPS satellite positioning system to track and monitor remote target by SMS or internet.
Features
1. Waterproof Grade IP66.
2. Strong magnet to absorb to vehicle firmly.
3. Built-in large capacity 10000MA battery.
4. Super long time standby, 6 months if it works under "sleep by time" mode and 6.9 years if it works under "schedule" mode.
5. Real-time tracking, movement alarm, Geo-fence alarm, shock alarm, remove anti-tamper alarm.
6. Support real-time tracking by mobile applications and web platform, and you can check the exact street address by cell phone as well.
7. Built-in high sensitivity GSM and GPS antenna, no installation, convenient and fast.
8. Anti-temper Alarm.
Wiring Diagram
| Content | Specifications |
| DIM. | 106mm x 63mm x 37.5mm |
| Weight | 343g |
| Network | 2G GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS sensitivity | -165dBm |
| GPS Accuracy | 5m |
| Time To First Fix | Cold starts: 30s
Aided starts: 5s
Reacquisition: 1s |
| Charger voltage | 110-220V input
5V output |
| Battery | Chargeable 3.7V 10000mAh Li-ion battery |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +55°C |
| Waterproof Grade | IP66 |
| Schedule mode | 10000*0.85 (battery self-lost) /0.14mA/24h/365d=6.9 years |
| Sleep Mode | Description | Application Occasions | Standby Time |
| Always online | GPRS is always online, tracker will be intelligent to shutdown some components to save power during the period which doesn't need to track. | The target need to be tracked by real-time. | 10000*0.9 (Battery self-loss) /4.5mA/24h=83 days |
| Sleep by shock | GPRS will be offline if it is motionless, vibration, calling can wake up the tracker, GPRS will be online if target is moving. | Sleep if the target is motionless, and track when the target start to move | 10000*0.9(Battery self-loss)/2.1mA/24h=178 days |
| Sleep by time | The GSM module of the tracker will run in low power mode no matter it is motionless or moving, vibration cannot awake the tracker, but calling can wake it up to works 3 minutes and then sleep again. | The target doesn't need to be tracked frequently and can track it any time when necessary. | 10000*0.9(Battery self-loss)/2mA/24h=187 days |
| Deep sleep by shock | GPRS and GPS module will shut down during sleep time, calling cannot reach, but vibration can wake up. | Sleep if the target is motionless, and track when the target start to move | 10000*0.85(Battery self-loss)/0.24mA/24h/365d=4 years |
| Schedule | GPRS and GPS module will shut down during sleep time, calling cannot reach and vibration cannot wake it up, but it will wake by itself to report its position at the scheduled time | The target doesn't need to be tracked frequently and let it report positions according to the schedules. | 10000*0.85(Battery self-loss) /0.14mA/24h/365d=6.9 years |
| Deep sleep by shock + schedule | GPRS and GPS module will shut down during sleep time, the tracker will wake up at the scheduled time or when it detect vibrations. | The target need to be tracked when it start to move and let it report positions according to schedule when it is motionless. | 10000*0.85(Battery self-loss) /0.24mA/24h/365d=4years |
Web online tracking www.gpstrackerxy.com
Demo Account: Demo
Password: 8888
Mobile APP"Tracker Home"
Certification: CE FCC
Company Information
Shenzhen Coban Electronics co., Ltd is a private export-oriented enterprise founded in 1999, 90% of the products are exported, and we have many years of research and development, production and management experience in automotive electronics, security products, wireless communications terminal equipment, and other fields.As a high-tech enterprises,we have a strict management system, and have obtained the authentication of CCC, CE, FCC and UL ISO9001, etc. So far, our products have been well marketed in 107 countries and regions in the world. Our company has set up research and development centers, including GPS R & D department, GSM R & D department and system integration Department. All the products are developed independtly and obtained a number of national patents. So the professional R D team, efficient production team provide good foundation with high-quality products. Quality has always been part of the company's most stressed. Before all the products entering the market, they have been tested rigorously such as high and low temperature aging test, vibration test, the noise tests, audio and video indicators decomposition tests.Our company specialized in GPS tracker, car anti-theft alarm system
Delivery
1. Sample and small order will be delivered within 2-3 working days after the receipt of payment.
2. For order over 500pcs or customized order, lead time will be 3 to 5 work days
after the receipt of payment.
Warranty
1. All products have been strictly Quality Checked in house before packing.
2. All products have been well packed before shipping.
3. One year warranty is provided for all models.
4.We will bear maintenance cost during warranty.
