Weather Protected Isolating Switch Epi

Name: Weather Protected Isolating Switch Epi
Brand: all-electronics-online.com
SKU: 768838145
Availability: InStock
Rating: 4.8 (54 reviews)

Price:	US $ 1.1/Piece
Trade Terms:	FOB
Min Order:	240/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	Weather Protected Isolating Switch EPI
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Product Standard:	En/IEC60947-3
Producnt Unumber Of Poles:	1p 2p 3p 4p
Rated Currents:	16,20,25,32,40,50,63,80,100,125A
Rated Voltage:	1pole 230/400V AC 50/60Hz
Lcw:	12le,L=Ls
Type Of Terminal:	Lug Type Pin Type
Degree Of Protection:	IP 20
Width:	17.8 mm Per Pole
Product Installation:	Mounting on 35mm DIN Rail
Rated Insulation Voltage Ui:	690V
Type:	Low-voltage
Structure:	Single-column Disconnector
Installation:	Indoor High-voltage
Operation:	Electric
Grounding:	Single Ground
Series:	Three
Run:	Turn the Horizontal
Switching Mode:	Single Throw-in
Certification:	RoHS
Brand:	Metworld

Product Description

MODEL	UN(V)	NUMBER OR POLES	RATED CURRENT IN	UTILIZATION CATEGORY
ST1	230/400VAC	1,2,3,4	16,20,25,32,40,50,63,80,100,125A	AC-22A

STI1 main switch is designed to accept cable-in/cable-out connections. It may be used as an isolating switch. The switch disconnected is capable of switching both resistive and inductive loads. The product conforms to IEC60947-3.

standard	EN/IEC60947-3
producnt unumber of poles	1P 2P 3P 4P
rated currents	16,20,25,32,40,50,63,80,100,125A
rated voltage	1pole 230/400V AC 50/60Hz 2,3,4 pole 400V AC 50/60Hz
lcw	12le,l=ls
type of terminal	lug type pin type
degree of protection	IP 20
width	17.8 mm per pole
product installation	mounting on 35mm DIN rail
rated insulation voltage Ui	690V
rated impulse withstand voltage Uimp	4000V
terminal capacity	Cables up to 50 square mm
rated short-circuit making capacity Icn	3le,1.05 Ue,COS =0.65
Trademark:	Metworld
Packing	Box/12 PCS; Carton /120PCS
specification	semko ce cb kema
HS Code:	8536200000
