Weighing Scale Feet Load Cell (BR215) Patented Products Which Is Strictly Prohibited Imitation
| Price: |
Negotiable/Piece |
| Min Order: |
2/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
BR215 |
| Measurement Force: |
Compression Force Measurement |
| Size: |
67mm*112mm(Diameter*Height) |
| Product Type: |
Scale Load Cell |
| Design: |
Patented Products Which Is Strictly Prohibited |
| Pattern: |
Load Button |
| Feature: |
High Accuracy |
| Production Process: |
Put on Strain Gauge |
Product Description
1. Name: Weighing scale feet load cell
2. Type: BR215 load cell
3. Specification
The BR215 load cell can be used to measure static compressive load. We could install this on the platform scales, weighing scales to replace the traditional beam load cells.- Low profile,small deflection, easy installation
- Made of stainless steel or Alloy steel
- Could replace the adjust feet of traditional platform scales
- Suitable for force measurement in limited spaces.Widely used for industrial measurement and control
- Patented products, which is strictly prohibited imitation
Brans force transducer offers IP67(IP68) protection. Precise measurement results are guaranteed even in adverse environments thanks to the hermetically sealed housing from stainless steel and rugged cable. Compact, precise, rugged - these characteristics make our load button highly versatile. Possible fields of application include:
Cost-effective test benches for a wide range of applications control and monitoring of production processes measurement tasks in development, when other sensors are too big, e. g. for measuring braking forces directly in the brake caliper. Furthermore, the compressive force transducer adapts to the application - cable lengths and connectors are variable. The sensor's identification number will be automatically detected and the amplifier automatically configured.
4. Key Features
Compact design
Direction of force: Compression
Accuracy class 0.2
Nominal rated forces: 0.5 to 2.5t
Configurable with different cable lengths, plug assembly
5. Datasheet| 1 | Specifications | Technique |
| 2 | Capacity | 0.5,1,1.5,2,2.5t |
| 3 | Rated output | 2.0±0.1%mV/V |
| 4 | Zero balance | ±0.03 mV/V |
| 5 | Non-linearity | 0.05%F. S. |
| 6 | Hysteresis | 0.05%F. S. |
| 7 | Repeatability | 0.02%F. S. |
| 8 | Creep(30min) | 0.05%F. S. |
| 9 | Temp. effect on output | 0.05%F. S. /10ºC |
| 10 | Temp. effect on zero | 0.05%F. S. /10ºC |
| 11 | Input impedance | 780±20Ω |
| 12 | Output impedance | 700±10Ω |
| 13 | Insulation | ≥5000MΩ/100VDC |
| 14 | Recommended excitation | 10V |
| 15 | Maximum excitation | 20V |
| 16 | Compensated temp range | -10~60ºC |
| 17 | Operation temp range | -20~80ºC |
| 18 | Safe overload | 150%F. S. |
| 19 | Ultimate overload | 300%F. S. |
| 20 | Cable size | φ4×4000mm |
| 21 | Material | Stainless Steel |
| 22 | IP Class | IP67 |
All of these load button load cells could be customized. The accuracy could be 0.1% for force measuring and controlling progress. www.bransensor.com
What you could get from Brans?
Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.
Why choose Brans?
Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.
We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.
Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.
Who Brans cooperate with?
Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
