Whip Ceramic Microstrip Antenna

Name: Whip Ceramic Microstrip Antenna
Brand: all-electronics-online.com
SKU: 728860612
Availability: InStock
Rating: 5 (77 reviews)

Price:	US $ 9.5/Piece
Min Order:	500/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Impedance:	575Ω
Gain:	28dB±2dB
Usage:	GPS
Operating Wavelength:	Microwave
Directionality:	Omnidirectional Antenna
Material:	N/a
VSWR:	Less Than 2.5
Base Antenna:	Automotive Antenna
Nature Of Operation:	Recieve and Transimit
Sturcture Form:	PCBA with Cable
Dimensionality:	Linear

Product Description

Whip Ceramic Microstrip Antenna

Product Specification:

Item				Specification
GPS Antenna	Ceramic Microstrip Antenna	CF		1575.42MHz
		BW		CF±5MHz
		Polarization		RHCP
		Gain		2.5dBic(Zenith)
		VSWR		<=1.5
		Axial Ratio		3dB(max)
		Impedance		50Ω
	LNA	Gain		28±2dB
		NF		<=1.5
		VSWR		<=2.0
		With table attenuation		30dB@CF+50MHz/20dB@CF+50MHZ
		Supply voltage		3.0V-5.0V
		Current consumption		<=25mA
AM/FM Antenna		Working Frequency	AM	520-1710kHz
			FM	87.5-108MHz
		Polarization		Linear polarization
		Average gain		>=-4dBi
		Input resistance(FM)		75Ω
AM/FM LNA		Gain		AM:6dB±2dB(Voltage gain)
				FM:10dB±2dB
		AGC		30dB
		VSWR		<=2.5@FM Band
		Noise voltage		AM:<=-6dBuV
				FM:<=-5dBuV
		DC		8-24V
		Current consumption		<=80mA
		Output impedance		75Ω

Company Profile
CTW is founded in the end of 2013. We a aglobal professional provider for connectors, antennas and wire harness.

We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.

Global professional provider for antennas ,cable assembly, precision parts & assembly, industrial connectors.

Dedicated to provide innovative solutions & high quality products for industrial, telecommunication, military, medical and automotive markets.

Professional & experienced R&D/Engineering team who are dedicated on research and development.

Rigorous and controlled manufacturing process and excellent quality system.

R&D Strategy & Capability

*Grow revenue and profit by innovation by providing new technology and competitive new design to customer

*Build strong research and development team

*Re-investment in R&D

*Completed and competitive R&D system

*High level design analysis capability (FEA/Moldflow/HFSS)

*Completed laboratory lab
FAQ
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.

Q:May I visit your factory?
A: Sure, welcome any time.

Q: What's your company MOQ?
A: our company don't have MOQ. We also accept small quantity.

Q: Can your company accept customize?
A: Welcome OEM & ODM.

Q: What's your delivery time?
A:If our company have stock ,will send to you within one day once receive your deposit.
If use customer brands, we will take some days to prepare materials and mass production.

Q: How do you solve after sale service?
A: This please ask us for technical support if you have workers know how to repair.
If do not have engineers, please send back the items, we can repair the items for you or we will re-produce for you.

Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, if the samples cost is very higher , we will ask a sample fee.At the same time. the Sample fee will return back in future order. If the
samples cost is lower, we can send it to you free, but shipping cost will be took .

CTW is founded in the end of 2013. It is a private enterprise.

CTW is a global professional provider for connectors, antennas and wire harness,

We are dedicated to providing innovative solutions & high quality products for industrial, telecommunications & networking, military, medical and automotive markets.

We have got the ISO9001 and TS16949 certification.

Our revenue was 1millon USD in 2014, 2.5millon USD in 2015, will be up to 4.5 millon USD in 2016

We have:

- Professional & experienced R&D / Engineering team who are dedicated to reserch and development;

- Early involvment and collaborative design capability;

- Rigorous and controlled manufacturing process and excellent quality system;

- Strong project management team focus on early involvement, time to marked, cost control and others;

Our company name is CTW: Connector the world. Our product is around the world and industrial area is our prospect.
