| Prod Model: |
Solid Electric Wire |
| Conductor: |
30-4/0AWG Solid/Stardard Bare Copper/Tinned Cooper |
| Insulation: |
PVC |
| Color: |
Any |
| Voltage Rating: |
600V |
| Test Voltage: |
2000V |
| Temperature: |
105 Degree |
| Flame Test: |
UL VW-1 & CSA FT1 & Jqa F-MARK Flame Test |
| Application Standard: |
UL 758, UL 1581 & CSA C22.2 No.210.2 |
| Name: |
UL1007 Solid PVC Electric Wire |
| Type: |
Insulated |
| Conductor Type: |
Stranded |
| Application: |
Underground |
| Conductor Material: |
Copper |
| Insulation Material: |
PVC |
| Certification: |
RoHS |
| Brand: |
Jiukai or OEM |
Product Description
Wholesale From China ul1007 Solid PVC Electric Wire
Product Description & Parameters
For general purpose internal wiring of electronic and electrical equipment, Max temperature 60C/80C when exposure to oil environment. Can be replaced by UL3386. Max 2.5KV when use in electronic equipment.
The oil resistance type cable is available
Uniform thickness of wire to ensure easy stripping and cutting. Oil-resistance to acid and alkali, moisture proof, mould proof, environmental etc.
Part-N0 | Conductor | Insulation | Insulation | Conductor Resistance |
| AWG | No./mm | Thickness(mm) | Diameter(mm) | at 20C MAX(Ω/km) |
| 003102001 | 26 | 7/0.160 | 0.79 | 2.05 | 150 |
| 003102002 | 24 | 11/0.160 | 0.79 | 2.2 | 94.2 |
| 003102003 | 22 | 17/0.160 | 0.79 | 2.35 | 59.4 |
| 003102004 | 20 | 26/0.160 | 0.79 | 2.55 | 36.7 |
| 003102005 | 18 | 41/0.160 | 0.79 | 2.8 | 23.2 |
| 003102006 | 16 | 26/0.254 | 0.79 | 3.05 | 14.6 |
| 003102007 | 14 | 41/0.254 | 0.79 | 3.45 | 8.96 |
| 003102008 | 12 | 65/0.254 | 0.79 | 3.95 | 5.64 |
| 003102009 | 10 | 65/0.320 | 0.79 | 4.6 | 3.54 |
| 003102010 | 22 | 7/0.254 | 0.79 | 2.35 | 55.27 |
| 003102011 | 20 | 7/0.320 | 0.79 | 2.55 | 34.5 |
| 003102012 | 18 | 7/0.391 | 0.79 | 2.8 | 21.76 |
| 003102013 | 26 | 1/0.404 | 0.79 | 2 | 143 |
| 003102014 | 24 | 1/0.511 | 0.79 | 2.1 | 89.3 |
| 003102015 | 22 | 1/0.643 | 0.79 | 2.2 | 56.4 |
| 003102016 | 20 | 1/0.813 | 0.79 | 2.4 | 35.2 |
| 003102017 | 18 | 1/1.020 | 0.79 | 2.6 | 22.2 |
| 003102018 | 16 | 1/1.290 | 0.79 | 2.9 | 14 |
| 003102019 | 14 | 1/1.163 | 0.79 | 3.2 | 8.78 |
| 003102020 | 12 | 1/2.050 | 0.79 | 3.6 | 5.53 |
| 003102021 | 10 | 1/2.588 | 0.79 | 4.2 | 3.47 |
Packaging & Shipping
Packaging Details:Delivery Detail:
Package:
1. Plastic/Wooden Drum: 100M/Roll,500M/Roll,1000M/Roll.
2. According to customer requiremet. |
| 7-15 days |
Certification
We passed UL, CCC, CE, VED etc. UL-E342399
I will give you copy of certification if you need more information.
Related Produce
1: Solar Cable
2: Electric Vehicle Charging Cable
3: Elevator Cable
4: Coaxial Cable
Why Choose Us:
We are a professional wire and cable manufacturer
Quality control: Our defective products rate is 0.01%
Economically priced, exquisitely made
Adequate supply capacity, punctual delivery time
Best of sales service are provided
Company information
Shanghai Jiukai Wire & Cable Co., Ltd is a national high and new tech enterprise. We consistently dedicate to the R&D, production and sales of wires and cables. We are professional HV&LV power cables, LV electrical wires and security cables in China. We introduce the most advanced automatic production lines, first-class testing & inspection equipments and laboratory for cable security test and application test. We have the technical team of local & overseas experts in cable industry. Strict quality control and safety policy ensures our products meet and exceed the GB industry standards. Our Cables are well sold to Americas, Europe, Middle-east, Southeast Asia and Africa. We establish the strategic partnership with many global electronic enterprises. We mainly produce nearly 10 categories (thousands of kinds) cables, such as audio & video cable, elevator cable, data cables, computer cable, CAT5E LAN cable , CAT 6 LAN cable, solar PV cable, UL wire, flexible cable and special cable. All our cables has already got the certificates of national or international professional testing organizations,such as China CCC certificate , US UL certificate , European Union CE Certificate , German TUV, Quality system certification certificate ISO9001:2000. And we get the honors of "Re-contract And Trustworthy Enterprise ","Measurement Qualified Enterprises" , "China Top Brand" and "China Cable Manufacturer TOP 100 ".
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.
