Widely Used Power Cable AAC Cable for Saving Energy
| Price: |
US $ 50/Meter |
| Min Order: |
100/Meter |
| Pay Type: |
L/C,T/T |
| Prod Model: |
Asian Sun Da Yuan |
| Sample: |
Free |
| Freight: |
Customer Pay for It |
| Company: |
Manufacture |
| Employee: |
800-1000 People |
| Application: |
Power Station |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
AC Cable |
| Insulation Material: |
XLPE |
| Certification: |
TUV |
| Material Shape: |
Stranded |
| Wire Core Material: |
Copper, Aluminium, as Per Client's Request |
| Model: |
Yjv, Yjlv22 |
| Brand: |
Asian Sun Da Yuan |
Product Description
1Products application
XLPE polyethylene insulated power cables , this product is applicable to being fixedly laid on the transmission and distribution line of alternative current rating 50 Hz and rated voltage up to 6/35 kv with the use fo power transmission, which is applied to the range of distribution network , industrial equipments, high electricity consumption places etc. XLPE polyethylene insulated flame-retardant power cables,the product has good performance on preventing fire burning on the circuit, which can avoid fire accident and losses .The products can be used in subway , tunnels and hig-rise buildings etc.
XLPE polyethylene insulated low-smoke zero-halogen falme-retardant powe cables, the environmental product has good performance on flame-retardant, corrosion resistance and low-smoke,which is wuitable to be laid in crowded places, such as subway, shopping mall or schools etc. This product is the normal used cable ,not suitable for some special places , such as under water, ship, nuclear station ,etc.2Technique features
XLPE polyethylene insulated power cables, this product is manufactured by parasitical cross-linking procedure, the straight-chain polyethylene will be changed as network structure by use this method, which transformed thermoplastic material into thermosetting material. The working temperature is up to 90ºC,which can raise the cabel current capacity highly.
XLPE polyethylene insulated power cables, the product has good performace on electrical characteristic, heat resistance, chemical resistance, environmental stress cracking resistance and aging resistance, all which make the cable has a long usefol life.
XLPE polyethylene insulated low-smoke zero-halogen flame-retardant low-smoke zero-halogen flame-retardant power cables; the product is a new environmental protected cable with good flame-retardant performance, which just releases few poisonous and corrosive gases. The product has good performance on electrical characteristic, heat resistance, chemical resistance, environmental stress cracking resistance and aging resistance, all which makes the cabel has a long useful life.
The product characteristis is simple structure, short production period, easy installation and maintained, especially there is no limit of head drop during the cable laying .3Operating characteristics The rated temperature of conductor
The maximum assigned temperature of the cable conductor is 90ºC.
During having a short circuit, lasting less than 5 seconds, the maximum temperature of the cable conductor shall not be above 250ºC .
Ambient temperature for laying
The ambient temperature for laying shall be above 0ºC,otherwise the cable need be preheated.
The bend radius
The ninimum bend radius of the cable 4Specification of product | Noninal cross area of conductor/mm² | Number of cores |
| 3.6/6kv | 6/6kv
6/10kv | 8.7/10kv
8.7/15kv | 12/20kv | 18/30kv | 21/35kv | 26/35kv | |
| 10 | - | - | - | - | | | |
| 16 | - | - | - | - | | | |
| 25 | 25 | 25 | - | - | | | |
| 35 | 35 | 35 | 35 | - | | | |
| 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| 70 | 70 | 70 | 70 | 70 | 70 | 70 | |
| 95 | 95 | 95 | 95 | 95 | 95 | 95 | |
| 120 | 120 | 120 | 120 | 120 | 120 | 120 | |
| 150 | 150 | 150 | 150 | 150 | 150 | 150 | |
| 185 | 185 | 185 | 185 | 185 | 185 | 185 | |
| 240 | 240 | 240 | 240 | 240 | 240 | 240 | |
| 300 | 300 | 300 | 300 | 300 | 300 | 300 | |
| 400 | 400 | 400 | 400 | 400 | 400 | 400 | |
| 500 | 500 | 500 | 500 | 500 | 500 | 500 | |
| 630 | 630 | 630 | 630 | 630 | 630 | 630 | |
| 800 | 800 | 800 | 630 | 630 | 630 | 630 | |
| 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | |
| 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | |
