WiFi/3G Network Advertising Player/PCBA (FEI302)

Prod Model:	FEI302
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mode Of Production:	SMT
Base Material:	FR-4

Product Description

1. Support LAN/WAN, wired/ WiFi(optional), 3G(optional)
2. Playback formats: Video: MPEG1/2/4, Audio: MP3, Image: JPG / BMP, Text: TXT
3. Complimentary server operations, simple and quick, easy to use
4. Server manage and control and watch alladvertising terminals on real time
5. Support 2.5-inch hard disk or CF card (CF card is recommended to use first)
6. Output Interface: VGA / CVBS / RCA stereo audio and video
7. LAN port: Internet 10/100M Base, wireless LAN: 802.11b / g
8. Server monitor the working statements of the terminal and node information
9. Scrolling text information can be immediately sent to the terminal Player from Server
10. Supports video / picture / text scrolling subtitles sub-screen playback, and full-screen playback (video / pictures)
11. When the internet is disconnected, the machine will play content as a stand-alone version with the playlist order time
12. Through the network automatically or manually update the play content
13. Text settings can select the font size and background colors
14. A high degree of security and system integrity closed
15. Based on the actual situation can be arbitrarily divided into many different areas of the picture and scroll subtitle player, video player area can customize options
Chipset SUNPLUS
Power supply DC IN: 12V
LED Indicators LAN LED, Run LED and Power LED
Board Size 140mm x 110mm x21mm
Board jack a: Audio & video signal, VGA signal
B: DC input and output jack (12V)
C: CF card reader slot or 2.5 inch HDD
D: IR receiver
E: LAN jack(RJ45), USB disk jack
F. Wirless Antenna
Playback Format Video: MPEG-1, MPEG-2, MPEG-4(mpg, AVI, dat)
Audio: MP3 TXT: TXT
Picture: JPG BMP
Componets Including:
AP63 software AP63 PCBA
Remote controller
2G CF card
