Wires and Cable Testion Force Load Cell (BR253)

Name: Wires and Cable Testion Force Load Cell (BR253)
Brand: all-electronics-online.com
SKU: 833735335
Availability: InStock
Rating: 5 (41 reviews)

Price:	US $ 25-30/Piece
Min Order:	3/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	BR253
Capaciy:	100g,200g,500g,1kg,2 Kg
Pattern:	Ring Type
Out-Wire:	5 Wires
Feature:	High Accuracy
Production Process:	Strain Gauge
Material:	Aluminum

Product Description

Brans B253 load cells is the Load Cells are major players when measuring the tesionforce of load directly. This Series offers a variety of capacities and inner diameter sizes making it ideal for bolt fastening applications.
Products in use our Load Cell paired with Instrumentation.

Datasheet

Number

Specifications

Technique

Capacity

100g,200g,500g,1kg, 2kg

Rated output

1.0±10%mV/V(300g,500g)

2.0±10%mV/V(1~5kg)

Zero balance

± 0.05mV/V

Non‐linearity

0.050%F.S.

Hysteresis

0.050%F.S.

Repeatability

0.050%F.S.

Creep(30min)

0.030%F.S.

Temp.effect on output

0.03%F.S./10ºC

Temp.effect on zero

0.03%F.S./10ºC

Input impedance

380±40Ω

Output impedance

380±40Ω

Insulation

≥5000MΩ/100VDC

Recommended excitation

Maximum excitation

10V

Compensated temp range

‐10~60ºC

Operation temp range

‐20~80ºC

Safe overload

150%F.S.

Ultimate overload

200%F.S.

Cable size

φ4×4000mm

Weight approx.

0.1kg

Material

Aluminum

IP Class

IP65

Key points

Made of aluminum alloy
High accuracy with strong anti-deflective loading
Easy to install with IP65 protection
Mainly used for measuring and controlling of tension force of wires

BRANS Load Cell is built for press or inline compression applications. The standard ring load cell has a very robust construction available in 17-4 PH stainless-steel, with an I.D. range of 1/8 in to 1-1/4 in and a 10 ft [3 m] #24 AWG, 4 conductor, braided shielded Teflon cable. You will also find the option for external matched output readily available.

Brans Load Cell offers high accuracy and high stiffness. It has a nonlinearity of ± 0.5% of RO, a deflection of 0.002 in [0.05 mm] nominal, and an operating temperature of -60° F to 200° F. The standard LTH500 can be modified or customized to meet your requirements and most capacities are in our inventory, making them available for 24 hour shipping. Similar to our entire Load Cell product line, this model is manufactured in the USA and uses metal foil strain gauge technology.

Customized Ring type load cells, please come to Brans Technology. www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
