| Prod Model: |
GPT15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Weight: |
65g |
| GSM Frequency: |
850/900/1800/1900MHz |
| Working Voltage: |
3.7VDC |
| Dimension(mm): |
96(L) X 50(W) X 11.2(H) |
| Bluetooth: |
Yes |
| Light Sensor: |
Yes |
| Positioning Mode: |
WiFi/GPS/Lbs |
| GPS Positioning Accuracy: |
5-15m |
| GPS Frequency: |
1575MHz |
Product Description
Company IntroductionFounded in 2004 year, we mainly engaged in GPS products which is based on GSM/GPRS wireless communication network and GPS or Beidou ,Gnolass positioning system. After 10 years development, we accumulate more and more experiences specializing in Internet Platform/App/GPS trackers.Our professional team guarantee technology advancement for Eelink products. Meanwhile we have advanced management system, complete QC and QA systems as well as strict testing methods to guarantee high quality.
We can provide: GPRS/WCDMA or GSM+GPS vehicle tracker,
Wireless long standby time GPS vehicle tracker,
OBD vehicle tracker,
Vehicle tracker for temperature or fuel detect,
Personal/Portable/Wearable GPS tracker,
GPS Watch, GPS Phone.
Our products are widely used in positioning and tracking vehicle,personal,pet and assets.This will realize the management for vehicle,person and cargo meanwhile the complete care for the elder and child.
Eelink can truly understand your specific needs and complete different clients' requirements in terms of new designs, high quality and large production.
2G Luggage GPS tracker GPT15GSM luggage GPS tracker GPT15 is born for the safety and security of luggage. Gpt15 could position, track the luggage, asset, valuables etc.Real time tracking, history playback, low battery alarm, Geo-fence alarm, Bluetooth Anti-lost could be viewed or set on the tracking platform.You can know the real time location and history route your luggage has been going.
Bluetooth Anti-lost function needs to connect the mobile Bluetooth. Mare sure to open the Bluetooth function of cellphone.
Application: Luggage, Suitcase, Assets, Valuables, technology researchers.
PRODUCT FEATURES:Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
GPS/LBS /wifi Positioning mode, support A-GPS
In-built 1800mAh Battery , recharged by USB port.
Real time tracking, history playback
Support Bluetooth V4.0 or above, Bluetooth anti-lost (need to open BT of cellphone, just shown on APP).
GEO-Fence Alarm, Low battery Alarm, brightness alarm.
Track by PC & APP online & SMS query
Support EELINK protocol and can be integrated to platform of customers
OTA upgrade firmware.
Alarm typeReal-Time Tracking
History Route Play Back
Remotely Setting
Geo-fence Alarm
Low battery Alarm
Bluetooth Anti-lost
Brightness alarm
Basic Specification| Voltage | 3.7VDC |
| GPS positioning accuracy | 5-15m (Depend GPS signal) |
| GSM Positioning Accuracy | About 100-1000m |
| wifi Positioning Accuracy | 15-50meters |
| GPS Frequency | 1575MHz |
| GSM Frequency | 850/900/1800/1900MHz |
| Hot/Warm/Cold Start time | <3s,<15s,<60s |
| Battery Capacity | 1800mAh |
| Dimensions (mm) | 96(L) × 50(W) × 11.2(H)) |
| Operating Temperature | -20ºC~70ºC |
| Operating Humidity | 20%~80%RH |
| Weight | 65 g |
Main function Table| Brand | EELINK |
| Model | GPT15 |
| Color | Black |
| Material | ABS, PC |
| Network | GSM |
| SIM Qty | 1 piece |
| Power voltage | 3.7V DC |
| GPS Chip | MTK |
| GPS Sensitivity | -163dB |
| GPS Channel | 20 |
| Real time Tracking | OK |
| History Play back | 90 days |
| SOS | No |
| Geo-fence Alarm | OK |
| Pedometer | No |
| Administrator cellphone No. | yes |
| Speed Alarm | No |
| Voice Call | No |
| Waterproof | No |
| Low battery Alarm | OK |
| Warranty | One year warranty excluding physical damage.Refer details in Manual |
Tracking PlatformYou can choose Keelin terminal monitoring platform or download APP by phone. It is both designed by EELINK, we can position, real time tracking and playback on the platform server or app. Meanwhile you can use your own platform which can support multiple protocols.
Platform website:
http://www.keelin.com.cn.
Choose language on the right corner and click demo for experience.
Shenzhen Eelink Communication Co. Ltd was founded in June 2004 aiming at technology Innovative. After 10 years development, we accumulate more and more experienced experts and senior engineers specializing in Internet Platform/APP/GPS trackers. Now we have a professional technology team engaged in software, hardware and industrial design, totally more than 50 engineers. This professional team guarantee technology advancement for Eelink products. Meanwhile we have advanced management system, complete QC and QA systems as well as strict testing methods to guarantee high quality.
Shenzhen Eelink Communication Co. Ltd can provide: GPRS+GPS tracker, WCDMA+GPS tracker, GPRS+Beidou tracker, Plug-in and play OBD vehicle tracker, Plug-in and play OBD diagnostics vehicle tracker, intelligent terminal for real time temperature and humidity checking. Our products are widely used in positioning and tracking vehicle, personal, pet and assets. This will realize the management for vehicle, person and cargo meanwhile the complete care for the elder and child. Eelink can truly understand your specific needs and complete different clients' Requirements in terms of new designs, high quality and large production, you will also enjoy the service of internet platform and smart phone APP for your GPS tracker.
We hold the faith to meet every customer' S needs to gain 100% customer satisfaction on quality products and after-sale service.
