Wr75 Rigid Waveguide for Vsat System
| Price: |
Negotiable/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
WR75 rigid waveguide |
| Frequency: |
1.14-173GHz |
| Cut-off Frenquency: |
907.91-90845GHz |
| Certificate: |
SGS, RoHS |
| Flange Type: |
Pdr/Pbr/Udr/Ubr |
| Quality Guarantee: |
100% Quality Inspection |
| Name: |
Straight Rigid Waveguide |
| Usage: |
Vsat System |
| Operating Wavelength: |
Microwave |
| Directionality: |
Directional Antenna |
| VSWR: |
<1.5 |
| Material: |
Al/Cu |
| Nature Of Operation: |
Antenna |
Product Description
Size | Frequency | Cut-off frequency | Inner section | Outer section | Weight |
| GHz | GHz | a | b | A | B | H96 | LF21 |
BJ14 | 1.14-1.73 | 907.91 | 165.1 | 82.55 | 169.16 | 86.61 | 9.04 | 2.81 |
BJ16 | 1.54-2.20 | 1157.1 | 129.54 | 64.77 | 133.6 | 68.83 | 7.13 | 2.21 |
BJ22 | 1.72-2.61 | 1372.4 | 109.22 | 54.61 | 113.28 | 58.67 | 6.03 | 1.87 |
BJ26 | 2.17-3.30 | 1735.7 | 86.36 | 43.18 | 90.42 | 47.24 | 4.81 | 1.5 |
BJ32 | 2.60-3.95 | 2077.9 | 72.14 | 34.04 | 76.2 | 38.1 | 3.96 | 1.23 |
BJ40 | 3.22-4.90 | 2576.9 | 58.17 | 29.08 | 61.42 | 32.33 | 2.6 | 0.81 |
BJ48 | 3.94-5.99 | 3152.4 | 47.55 | 22.15 | 50.8 | 25.4 | 2.1 | 0.65 |
BJ58 | 4.64-7.05 | 3711.2 | 40.39 | 20.19 | 43.64 | 23.44 | 1.84 | 0.57 |
BJ70 | 5.38-8.17 | 4301.2 | 34.85 | 15.8 | 38.1 | 19.05 | 1.54 | 0.48 |
BJ84 | 6.57-9.99 | 5295.7 | 28.5 | 12.62 | 31.75 | 15.88 | 1.27 | 0.4 |
BJ100 | 8.20-12.5 | 6557.1 | 22.86 | 10.16 | 25.4 | 12.7 | 0.79 | 0.25 |
BJ120 | 9.84-15.0 | 7868.6 | 19.05 | 9.525 | 21.59 | 12.06 | 0.69 | 0.22 |
BJ140 | 11.9-18.0 | 9487.7 | 15.8 | 7.899 | 17.83 | 9.93 | 0.46 | 0.14 |
BJ180 | 14.5-22.0 | 11571 | 12.95 | 6.477 | 14.99 | 8.51 | 0.39 | 0.12 |
BJ220 | 17.6-26.7 | 14051 | 10.67 | 4.318 | 12.7 | 6.35 | 0.31 | 0.1 |
BJ260 | 21.7-33.0 | 17357 | 8.636 | 4.318 | 10.67 | 6.35 | 0.27 | 0.08 |
BJ320 | 26.4-40.0 | 21077 | 7.112 | 3.556 | 9.14 | 5.59 | 0.23 | 0.07 |
BJ400 | 32.9-50.1 | 26344 | 5.69 | 2.845 | 7.72 | 4.88 | 0.2 | 0.06 |
BJ500 | 39.2-59.6 | 31392 | 4.775 | 2.388 | 6.81 | 4.42 | 0.17 | 0.05 |
BJ620 | 49.8-75.8 | 39877 | 3.759 | 1.88 | 5.79 | 3.91 | 0.15 | 0.05 |
BJ740 | 60.5-91.9 | 48369 | 3.0988 | 1.5494 | 5.13 | 3.58 | 0.13 | 0.04 |
BJ900 | 73.8-112 | 59014 | 2.54 | 1.27 | 4.57 | 3.3 | 0.11 | 0.04 |
BJ1200 | 92.2-140 | 73768 | 2.032 | 1.016 | 3.556 | 2.54 | 0.11 | 0.03 |
BJ1400 | 113-173 | 90845 | 1.651 | 0.8255 | 3.175 | 2.35 | 0.09 | 0.03 |
We have the largest Flexible waveguide production lines in the Asia Pacific Region.
Our factory floor area is about 5500 square meters,
And our factory can produces 9000 piece flexible waveguide per mounth.
We have participated in many exhibitions and entertaining Clients.
1. Top 1 flexible waveguide manufacturer in China.
2. We have many more professional experts than 20 years R&D experiences.
3. 100% quality inspection.
4. Products are sold to more than 50 countries.
5. Products pass Rohs, SGS test and many identifications from big customers.
6. We own many professional equipments.
7. We have strong sales and service team best service for you.
8. We accept customized design.
9. OEM&ODM service is supplied.
10. We have many technology patents and awards.
Selling Units: Single item
Single package size: 42X37X9 cm
Single gross weight: 3.0 KG
Package Type: wooden box/carton
HS code:85177090, 8544421900, 8307900000
1. Inquiry-Professional quotation.
2. Confirm the price, lead time, artwork, payment term etc.
3.Our sales send the Proforma Invoice with our seal.
4. Customer make the payment for deposit and send us Bank receipt.
5. Initial Production Stage-Inform the clients that we have got the payment,And will make the samples according to your request, send you photos or Samples to get your approval. After approval, we inform that we will arrange the production & inform the estimated time.
6. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.
7. End Production-Mass production products photos and samples will send to you for approval. You can also arrange the third party Inspection .
8. Clients make payment for balance and Ship the goods , Inform the tracking number and check the status for clients.
9. Order can be say "finish" when you receive the goods and satisfy with them .
10. Feedback to our about Quality , Service, Market Feedback & Suggestion. And we can do better
Shanghai HeXu Microwave company is a high-tech manufacturer, Benefit from our more than 10 years experiences. HEXU application engineers work with you to find cost-effective design solutions that meet your requirements.
The products mainly include rectangular flexible waveguide, Elliptical flexible waveguide, RF cable assemblies, Microwave components as well as ferrite devices, etc. Which are widely used in telecommunication, satellite communication, radio and TV, medical and military industry, radar applications etc.
Our factory established in 2011 and our trading company founded in 2012. ISO certificated factory.
