Ybl12A-a 12V 12ah Powersports Battery

Prod Model:	YBL12A-A Yuasa 12V 4A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Powersports Battery:	Ybl12A-a 12V 12ah Powersports Battery
Type:	Lead-Acid Batteries
Usage:	Boat
Rechargeable:	Chargeable
Discharge Rate:	Low Discharge Rate
Shape:	Square Battery
Nominal Voltage:	12V

Product Description

YB12A-A is a high-performance conventional battery with polyethylene glass mat separator. It utilizes top lead alloy that contains calcium alloy for increased weld strength and severe vibration resistance.

Features
Voltage: 12 volt
Capacity: 12Ah
Cold Cranking Amps: 165A
Cast Grid: Severe vibration resistance & improved conductivity
Active Material: Reduced shedding, maximum utilization and long service life
Pasted Plates: Ensures vibration resistance through precise compression and proper service life
Dried-Charged Plates: Limitless shelf-life while retaining 70~80% state of charge when initially filled with acid
Top Lead Connections: Shorter current path for increased electrical conductivity and higher starting currents
Case-Cover Seal: Prevents air ingress & acid seepage
Terminal-Cover Seal: Patented Poly-Seal to eliminate acid seepage, reduces corrosion and extends battery life
Case & Cover: Superior resistance to gasoline and oil, impact resistant in extreme weather conditions
Additive: Sulfate stop to reduce the solubility of lead into acid which then reduces battery sulfation
Grid System: Increased conductivity for higher starting wattage, increased vibration resistance
Separator: Polyethylene with glass mat sheet bonded for compression to withstand severe vibration conditions

Acid Pack Not Included: Ships without acid. Acid packs may be purchased at most large auto parts stores. Must be filled and charged prior to use.
Specifications
Chemistry Dry Charge AGM
Capacity 12Ah
Rating whr144
Cca 165
Cellnum 6
Connector 5
Length 5.25 inches
Width 3 inches
Height 6.25 inches
Weight 6.30 lbs

Replace Yuasa & Other Suppliers #	Voltage  (V)	Capactiy 10HR(Ah)	Dimensions(±1mm)
			L	W	H	HL
YTX5L-BS	12	4	114	70	105	105
YTX9-BS	12	8	150	87	105	105
YTX7A-BS	12	6	150	87	93	93
YTX12-BS	12	10	151	87	130	130
YB4L-B	12	4	120	70	92	92
YTX14-BS	12	12	151	87	146	146
YB9-B	12	9	135	75	138	138
YTX7L-BS	12	6	114	70	130	130
6N11A-3A	6	11	121	59	129	129
Y50-N18L-A	12	20	206	92	160	160
